127408-YIM-B-0606
Unitary Products Group 19
TABLE 10: ELECTRICAL DATA 7-1/2 TON
Voltage
*
Compressors
OD
Fan
Motors
Supply
Blower
Motor FLA
Pwr Exh
Motor
Electric
Heater
Model No.
Actual
kW
Heater
Amps
Min. Circuit
Ampacity
(Amps)
MCA
w/Power
Exhaust
(Amps)
Max Fuse
†
Size (Amps)
Max Fuse Size
w/Power
Exhaust
(Amps)
RLA
ea.
LRA
ea.
FLA
ea.
3 HP FLA 3 HP 2 HP 3 HP 2 HP
380
8.3 62 1.1 4.9 2.2 None - - 26.1 28.3 30 35
415
8.3 62 1.1 4.9 2.2 None - - 26.1 28.3 30 35
*.
Unit voltage limitations: minimum utilization 342 volts, maximum utilization 457 volts.
†.
Maximum HACR breaker of the same amp size is acceptable.
TABLE 11: ELECTRICAL DATA 10 TON
Voltage
*
Compressors
OD
Fan
Motors
Supply Blower
Motor FLA
Pwr Exh
Motor
Electric
Heater
Model No.
Actual
kW
Heater
Amps
Min. Circuit
Ampacity
(Amps)
MCA
w/Power
Exhaust
(Amps)
Max Fuse
†
Size (Amps)
Max Fuse Size
w/Power
Exhaust
(Amps)
RLA
ea.
LRA
ea.
FLA
ea.
2 HP
(1.5 kW)
4 HP
(3 kW)
FLA
2 HP
(1.5 kW)
4 HP
(3 kW)
2 HP
(1.5
kW)
4 HP
(3 kW)
2 HP
(1.5 kW)
4 HP
(3 kW)
2 HP
(1.5
kW)
4 HP
(3
kW)
380 9.6
80 1.1 5.2 7.5 2.2
None - - 29.0 31.3 31.2 33.5 35 40 40 40
2TP04521850 11.3 17.2 29.0 31.3 31.2 33.5 35 40 40 40
2TP04522450 15.0 22.8 35.0 37.9 37.7 40.6 35 40 40 45
2TP04523650 21.3 32.4 47.0 49.8 49.7 52.6 50 50 50 60
2TP04525450 33.8 51.4 70.7 73.6 73.4 76.3 80 80 80 80
415 9.6 80 1.1 5.2 7.5 2.2
None - - 29.0 31.3 31.2 33.5 35 40 40 40
2TP04521850 13.5 18.8 30.0 32.9 32.7 35.6 35 40 40 40
2TP04522450 17.9 24.9 37.6 40.5 40.4 43.3 40 45 45 45
2TP04523650 25.4 35.3 50.7 53.5 53.4 56.3 60 60 60 60
2TP04525450 40.4 56.2 76.8 79.6 79.5 82.4 80 80 80 90
*.
Unit voltage limitations: minimum utilization 342 volts, maximum utilization 457 volts.
†.
Maximum HACR breaker of the same amp size is acceptable.
