63L10 FTF8-12
63L13 FTF8-18
H0522 FTF8-24
63L14 FTF8-36
Chimney Section 63L15 FTF8-48
Locking Band 63L60 FLB
Thimble Extension 26" 91L46 F8-TE26
Adjustable Firestop/Thimble HO325 FM8-AT1
Adjustable Chimney Pipe Kits HO559 FM8-PK10
Stabilizer 63L25 FTF8-S4
INSTALLATION COMPONENTS
Ref. Form #750,080M
Firestop Spacer (Flat) (Single Pack) 63L29 F8FS
Firestop Spacer (Flat) (12 Pack) 94L76 F8FS-12
Firestop Spacer (30°) 63L30 F8FS30
Contemporary Termination -
Round 63L42 FTF8-CTD
Contemporary Termination -
Round, Black H2238 FTF8-CTDP
19M55 F8F6MH
19M56 F8F12MH
63L38 (0-6/12) F8F6
Flashing 63L39 (6/12-12/12) F8F12
Storm Collar 63L59 FSC
Storm Collar (12 pack) 94L77 FSC-B-12
Offset/ Return Package
30 Degree Offset/Return Elbow FTF8-ES30 63L22
15 Degree Offset/Return Elbow FTF8-OR15 63L28
Floor Inlet Assembly
FOAK-6 (standard)
Air Inlet Hood FOAK-6W
(optional)
6" Duct
Outside Air Kit (optional) 19M17 FOAK-6W
Outside Air Kit (standard) 90L83 FOAK-6
