16
WINDING THE BOBBIN
1. Place a spool of thread on the spool pin, and secure it with
the spool pin cap. Pull the thread out from the spool and
place it through thread guides as shown in illustration.
2. Put end of thread through the hole in bobbin as shown.
3. Push bobbin winder shaft to far left position, if it is not already
there. Place bobbin onto shaft with end of thread coming
from top of bobbin. Push bobbin winder shaft to the right until
it clicks. Hold onto end of thread.
4. Start machine. Bobbin will automatically stop turning when
completely filled. Push shaft to the left to remove bobbin and
cut thread.
1
2
3
4
