GETTING TO KNOW YOUR SHARK TURBO STICK VAC
Technical Specifications
Voltage: 120V., 60Hz.
Power: 7.5 Amps, 900 Watts
OPERATING INSTRUCTIONS
Replacing The Dust Cup Into The
Unit
• Hold the dust cup in your hand.
• Make sure that the slot on the bottom
of the cup is pointed in the same
direction as the pins in the unit (see
drawing #1).
• Slide the dust cup inside to the end of
its place in the unit (see drawing #2).
• Turn the dust cup 90° in the direction
shown in the drawing (#3) at right.
• The unit is now ready to be used
again.
Note: To keep the vacuum cleaner
looking new, it can be wiped with a damp
cloth and a mild soap solution, then
thoroughly dried. Never use any type of
chemical cleaners as they can damage
the vacuum cleaner. When not in use,
store the vacuum cleaner in a dry, clean
place.
Attaching the Shoulder Strap
Use the hooks to attach the shoulder
strap to the vacuum cleaner.
Connect the dog leash swivel hooks
to the eyelets located near the top of
the unit handle and at the base of the
unit. Adjust the strap as required for
comfort.
Warning: After extended use, the body
of the vacuum cleaner may become hot.
When using the unit with the shoulder
strap, the unit will touch the body of the
user. Therefore make sure to use the
vacuum cleaner with the strap only when
the unit is cool. If it gets too warm, allow it
to cool before continuing to use it.
Motor Thermostat
Hook for
Shoulder
Strap
Hook for
Shoulder Strap
IMPORTANT:
This unit is equipped
with a motor protective thermostat. If
for some reason the vacuum cleaner
should overheat, the thermostat will
automatically turn the unit off. Should
this occur:
• Push the On/Off button once.
• Disconnect the plug from the
power source.
• Check the source of overheating
problem. (i.e. clogged hose or
filter).
• If clogged hose or filter is found,
unclog the hose and replace the
filters.
• Wait at least 45 minutes before
attempting to reuse the vacuum.
• After unit has cooled down for
45 minutes, plug in the cleaner
and push the On/Off button. The
vacuum should start again.
• If the vacuum still does not start,
contact customer service at
1-800-798-7398.
* Note: Illustrations may differ from actual product
7
