OPERATING INSTRUCTIONS
NOTE: Always remove the power plug
from the wall outlet before assembling or
removing accessories.
Pin
Pin
Hole
ATTACHING THE FLOOR BRUSH
TO THE MAIN BODY
• Push in the pin in the floor attachment
as shown in the illustration at right.
• Insert the floor brush into its location,
in the direction
of the arrow.
• When inserted
correctly, the
pin will show in
the pin hole.
ATTACHING THE HOSE TO THE
MAIN BODY
• Press in the pin at the end of the
hose (see illustration below).
• Insert the hose into its place (see
arrow in illustration).
• When inserted correctly, the pin will
show in the pin hole.
Pin Hole
INSERTING THE 2-PIECE METAL
4
HANDLE INTO THE MAIN BODY
• Push in the pin at the end of the lower
piece of the metal handle (see
illustration).
• Insert the metal handle into the hole
next to the handle. Make sure that the
slot in the handle fits correctly into the
opening. (See illustration.)
• When inserted correctly, the pin should
rest in its hole.
• To insert the upper piece of the metal
handle, press on the pin that is on the
upper handle and insert into the lower
handle making sure that the pin comes
out of the pinhole on the lower handle.
OPERATING INSTRUCTIONS
WINDING & UNWINDING THE
POWER CORD
• To wind the cord
after usage, follow
the illustration below.
• To unwind the power
cord, follow the
illustration below
but in the opposite
direction.
Cord Holder
Top of Retractable Handle
• When using the vacuum, attach the
cord to the cord holder so that the
cord is out of the way when you are
vacuuming. (See below.)
USING THE UNIT AS A HAND
VACUUM
• Disconnect the metal handle.
(See page 4.)
• Disconnect the floor brush.
(See page 4.)
• Attach the hose. (See page 4.)
• Attach the crevice tool or the dusting
brush. (See below.)
• Attach the shoulder strap.
(See page 7.)
Crevice Tool
For radiators, crevices, corners,
baseboards and
between cushions.
Dusting Brush
The dusting brush is used for the
furniture, venetian blinds,
books, lamp shades
and shelves.
USING THE UNIT AS AN UPRIGHT
• Unwind the power cord and plug into
the 120V outlet.
• Push down in the direction of the arrow
to obtain best results on carpets or on
hard wood floors.
NOTE: When vacuuming
deep pile carpets or
hard to vacuum
carpets, lower the
angle of the 2-piece
metal handle
(see illustration at
below) for
easier
maneuverability.
5
• Hold the dust cup in your hand.
• Turn it a complete 90° in the direction
shown in drawing #1. (Turning less than
90° will cause the dust cup to be
attached on its bottom.)
• Let the dust cup come down slightly as
shown in drawing #2.
• Slide the dust cup out towards you (see
arrow in drawing #3).
• Hold the dust cup in your hand and
remove the HEPA-Type dust cup filter
(see drawing #4).
• Empty the dust cup (see drawing #5).
4
Emptying The Dust Cup
Warning: Always unplug the unit from
electrical outlet before opening the Dust
Cup (container).
5
ON/OFF SWITCH
• The On/Off switch has two different
positions.
• Push on the "I" side to turn the
vacuum ON.
• Push on the "O" side to turn the
vacuum OFF.
= OFF
= ON
