12
1161 0695
1
5
8
9
7
3
4
6
2
11
11
12
1
2
13
7A
• Not illustrated. * JSAFL-A, JSAEFL-A only.
REPAIR PARTS LIST
DURA-JET
TM
SPA PUMP
3/4 through 1-1/2 HP Models
Parts are common to all models listed except as noted;
Key Nos. 1, Motor; and 8, Impeller, are listed below.
Model Motor No. Impeller No.
No. HP (Key No. 1) (Key No. 6)
115 Volt Single Speed
JSACL-A 1/2 AS900CLL C105-228PC
JSADL-2A 3/4 AS920DLL C105-228PB
JSAEL-2A 1 AS920ELL C105-228P
115 Volt Two Speed
JSAYDL-A 3/4 AS900DLL-Y C105-228PB
JSAYEL-A 1 AS900ELL-Y C105-228P
115 Volt Two Speed (Low Speed Start)
JSAYDL-LA 3/4 A910DSLL-Y C105-228PB
JSAYEL-LA 1 A910ESLL-Y C105-228P
JSAYFL-LA 1
1
¼
2 A910FSLL-Y 17301-0101
115/230 Volt Single Speed
JSAFL-A 1
1
¼2 A910FLL 17301-0101
JSAEFL-A 1
1
¼2 AE910FLL 17301-0101
230 Volt Single Speed
JSADL-230A 3/4 AS923DL C105-228PB
JSAEL-230A 1 AS923EL C105-228P
230 Volt Two Speed
JSAYDL-230A 3/4 AS923DL-Y C105-228PB
JSAYEL-230A 1 AS923EL-Y C105-228P
JSAYFL-230A 1
1
¼2 A923FLL-Y 17301-0101
220 Volt Two Speed
JSAYDL-220A 3/4 62003-2004 C105-228PB
JSAYEL-220A 1 62003-2005 C105-228P
Key Part
No. Description Qty. Number
1 Motor 1 Chart at Right
2 Slinger 1 17351-0009
3 Seal Plate 1 C1-260P
4 “O” Ring 1 U9-357
5 Seal 1 37400-0027S
6 Impeller 1 Chart at Right
7 Front Plate 1 C101-262P
8 Pipe Plug 2 WC78-40T
9 Drain Plug 1 U178-920P
10 Screw, 1/4-20x1-3/4 6 30787-0005
11 “O” Ring, 2 U9-226
12 Adapter, Union 2 U11-183P1
13 Collar, Union 2 U11-182P1
• Nameplate 1 U33-155
• Decal - ”For Use with Pools
and Spas” 1 U27-635
• Voltage Label - 230V(-230A) 1 U27-68
• Voltage Label - 115V
(-A, -AA, -LA) 1 U27-67
• Voltage Label - 115/230V* 1 U27-153
• Warning Tag 1 C63-12
• Warning Tag 1 C63-13
