SPARE PARTS LIST AND EXPLODED VIEW - RESDELUX
-15-
Item Number Part Number Description
1 151-9002 Cylinder type 202
2 158-1820 Steam distributor kit
3 153-5062 Steam distributor
4 158-1830 Steam blower pack
5 158-1821 Steam Hose 4’ long
6 158-7104 Cabinet front door
7 185-3104 Lock assembly with keys
8 145-6000 Drain valve complete
8a 145-5002 Screw Drain Valve
9 132-6002 Drain valve coil assembly
10 132-6004 Drain valve o-ring
11 131-3244 Fill valve assembly
11a 145-5000 Fill valve gasket only
11b 145-5004 Fill valve screw
12 149-5072 Brass fitting with gasket
12a 132-6129 Elbow
13 158-1450 Fill cup assembly kit with hoses and clamps
13a 142-1050 Fill cup
13b 132-8850 Condensate hose (small dia.)
13c 132-8860 Condensate hose (medium dia.)
13d 132-5023 Clamp small house
13e 132-5035 Clamp medium hose
14 132-1216 Drain canal round
14a 132-5064 Screw drain canal
15 163-1026
Gasket for round drain canal
16 158-3511 Power control board (provide unit serial number when ordering).
17 150-1491 Transformer 120/24 Vac
18 158-3126 Fuse 1.5A
19 132-3097 On/Off/Drain switch
20 158-1309 Wire harness - drain & fill valves
21 158-1305 Wire harness - cylinder, complete
21a 135-4012R Cylinder plug RED
21b 135-4012B Cylinder plug BLACK
21c 132-4012W High water sensor pin
22 158-1311 Power Supply
23 158-1312 Blower Fan Assembly
24 150-2326 Wire extension for blower pack
Not Shown 132-8810 Steam Hose (Specify Length)
Not Shown 158-5001 Steam and condensate hose support bracket (Specify Quantity)
Not Shown 132-8841 Condensate Line (Specify Length)
