3. Rotate the mesh filter cover (20) clockwise to
disassemble the filter assembly.
4. Use the filter cleaning brush (22) to remove any
fluff from the outside of the mesh filter cover
(20)
or in between the pleats of the dust canister filter
(19).
IMPORTANT: The filter and cover may also be
washed but must be left to thoroughly air dry
before re-use.
IMPORTANT: Do not wash the filter and cover
with hot water or detergents.
IMPORTANT: Do not use heated appliances to
dry the filter or cover.
5. To re-assemble, locate the dust canister filter into
the lid then secure into place with the mesh filter
cover by rotating the mesh filter cover
anti-clockwise.
6. Fit the lid with filter assembly onto the canister,
then rotate clockwise until it locks into place.
7. Re-attach the dust canister to the main body.
Feed the base onto the unit first and push the top
back until it clicks into place. Then push the
hinged lid back into place to secure the canister.
Replacing the exhaust filter
To maintain high efficiency, the exhaust filter
should be replaced every 6 months.
The exhaust filter (15) is located behind the exhaust
filter cover
(14) at the rear of the vacuum cleaner.
1. Release the filter cover by pressing down on the
release lever.
2. Remove the exhaust filter.
3. To refit the filter, first hook the top of the filter into
the filter recess then push the bottom of the filter
into location.
4. After fitting the filter, re-fit the exhaust filter cover
by hooking the bottom of the cover in first and
then pushing the top into place until it clicks fully
closed.
Cleaning and maintenance
Unplug from the mains supply before cleaning.
The vacuum cleaner, especially the dust
compartment and all accessories, can be cleaned
using a damp cloth or a non-abrasive domestic
cleaner and wiped dry.
To keep the underside of the combination floor
nozzle clean, vacuum it at regular intervals using
the crevice tool.
Purchasing filters
Use only genuine replacement filters which can
be purchased from specialist retailers or by
calling our spare parts helpline number:
0844 873 0726.
