Operating / Assembly
1
Push the 360° rotating head on the hose (3) into
the hose inlet (4) on the vacuum cleaner.
To remove, press the buttons on the hose
connector and pull out.
2
Attach either the extension tubes or the
telescopic tube (2) (dependent on model) to the
handle end (1) of the hose (3). Extend the
telescopic tube to the required length by
pressing down the tube release button and
pulling out the tube. Attach the required
accessory to end of the tube.
3
Always pull out the power cord (11) to its
maximum length (indicated by the yellow tag on
the cable). Plug the appliance into the mains
supply. Push the On/Off button (9) to start the
motor.
IMPORTANT: Ensure that the appliance is never
left unattended whilst it is switched on.
4
Close Open
The suction power can be varied to suit the
surface being cleaned by using the Eco Switch
(10), (see the table on page 5 for guideline
settings).
The suction power can also be adjusted using
the suction control
(1) on the hose handle.
Closed: full suction
Open: reduced suction
5
During short breaks in cleaning, the tube(s) (2)
can be held in an upright, ‘standby’ position.
Rotate the floor nozzle (23) or (28) until the lug
on the neck can be fitted into the tube standby
slot (12) on the rear of the appliance, whilst you
move furniture for instance.
6
Switch off the appliance. Remove the plug from
the mains supply and rewind the power cable
using the cable rewind button (8).
WARNING: When using the cable rewind,
always hold the plug as the cable will rewind
quickly.
