Assembly
B
WARNING: Do not plug in the cleaner
until it is assembled.
1 Carefully unpack all components.
2 Lift cleaner body to upright position.
3 Remove the two screws that are already
attached to the body.
4 From the rear of the cleaner, align the
handle with groove and slide into the
body. If necessary, use thumb and finger
pressure to slide handle into position.
5 Fasten the handle with the two screws.
Floor nozzle height
adjustment
C
Before using the cleaner the floor nozzle
height must be set to the correct height.
Choose the setting which most closely
matches your floor surface.
• Use the DEEP CARPET setting when
using the tools.
Note: The height adjustment only comes
into effect when the handle is released by
the handle release pedal È.
Variable power
D
(Certain models only)
Slide the variable power control to the
right to increase the suction power or to the
left to decrease suction. This feature is most
useful when using the hose and accessories.
Use the minimum setting when vacuuming
delicate fabrics/curtains etc. When not using
the hose it is advisable to keep the variable
slider set to maximum.
Using on carpets
1 Place cleaner in its upright position.
2 Set the carpet height adjustment knob to
the desired position.
3 Release the mains cable by revolving the
quick release cleat
1
/
2
a turn and extend
the cable fully.
4 Plug the cable into the mains socket.
5 Step on the handle release pedal to
release the handle to the desired
position.
6 Press the on/off button to the ‘on’
position.
IMPORTANT: To prevent damage to
carpets, never leave the cleaner switched on
in one place for an extended period.
• Never have the brushes set too low such
that the cleaner is hard to push.
Using attachments
Follow steps 1-4 (using on carpets) but
set the carpet height adjustment knob to
deep carpet setting.
5 Remove the hose connector Í from the
rear of the cleaner. Lift the hose · from
the top handle hook. Insert the hose clip
˜ into the hose clip slot Ë.
4
B
DEEP CARPET HARD FLOOR
MEDIUM CARPET
TOOLS
C
min max
D
