Safety cut out
(brush-bar motor)
If a large item or rug edge jams
the brush-bar, a safety cut-out
will operate. If this happens,
switch off and unplug before
cleaning the blockage. Wait 1
minute before switching back
on.
Blockages
If the performance has
deteriorated, there may be a
blockage. Check the hose and
tools. Check the dust canister
inlet.
Check the floor nozzle hose Ó.
The upper end of the floor
nozzle hose may be
disconnected for inspection by
squeezing the release clips and
pulling down O. Clear any
blockages and refit securely
before re-use. Make sure the
clips are fully clipped back into
place.
Cleaning and
maintenance
Unplug from the mains before
cleaning. The vacuum cleaner,
especially the dust compartment
and all accessories, can be
cleaned using a damp cloth or a
non-abrasive cleaner and wiped
dry.
PURCHASING
REPLACEMENT
FILTERS
Use only original Morphy
Richards filters. These can be
purchased from Morphy
Richards by calling the helpline.
Accessing the floor
nozzle
The floor nozzle top cover may
be removed to clear any
blockages.
1 Switch off and unplug.
2 Release the upright section and
lay the cleaner flat on the floor.
3 Using a coin, rotate the rear
release clips a quarter-of-a-turn,
lift the rear of the cover and
un-hook from the front edge P.
4 Clear any blockage.
5 To refit, hook the
front edge in first
then close. Rotate
the rear clips a
quarter-of-a-turn
to secure.
6 Lift the upright
section back to
vertical until it
clicks into position.
Helpline
If you have any difficulty with
your appliance, do not hesitate
to call us.
We are more likely to be able
to help than the store from
where you bought it.
Please have the following
information ready to enable our
staff to deal with your query
quickly.
• Name of the product.
• Model number as shown on the
underside of the appliance.
• Serial number as shown on
underside of the appliance.
UK Helpline 0844 871 0949
Replacement Parts 0844 873 0715
Ireland Helpline 1800 409 119
P
Ó
O
For electrical products sold
within the European
Community. At the end of
the electrical products useful
life it should not be disposed
of with household waste.
Please recycle where
facilities exist. Check with
your Local Authority or
retailer for recycling advice
in your country.
