NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
9
PLACING GLOWING EMBERS
Remove the door (refer to Figure 6 ) by grasping
the door firmly at the bottom and supporting
the top. Lift up and away.
Place the orange plastic glowing ember coals
along the back of the ember bed, behind and
below the logs. Refer to Figures 13 and 14.
Reinstall the door. Catch all four tabs in the slots
located at the four corners of the unit inside of
the outer frame. Ensure the slots on the tabs
engage the face frame as the door drops into
place downwards.
Figure 13
Figure 14
Model Catalog Number Weight
MPE-27 H3428 78 lbs.
ACCESSORY PARTS AND COMPONENTS
FOR THE MPE-27
The accessory parts and components listed on
this page are to be used only with your MPE-27
electric fireplace. Separate installation instruc-
tions are packaged with all accessories.
If you encounter any problems or have questions
concerning the installation or application of this
system, please contact your distributor. For the
name of your nearest distributor contact:
LENNOX HEARTH PRODUCTS
1110 West Taft Avenue
Orange, CA 92865
ACCESSORY COMPONENTS
The following items are available for use with
this appliance.
Cabinet Surround Kit, Mantel
- Honey Oak H3432 SK-27O
Touch-Up Paint Kit
Repair of minor scratches and discoloration of
the appliance's painted surfaces may be accom-
plished with the use of this touch-up paint kit.
Touch-Up Paint Kit (Gray) H5093 TPK-GR
