NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
4
FRAMING SPECIFICATIONS
Figure 3
FIREPLACE SPECIFICATIONS
Front View
31-1/4"
(794 mm)
Side View
25"
(635 mm)
Note: Framing dimensions are calculated for an in front of the
wall front face installation with finish dry wall in place.
11"
(280 mm)
32"
(833 mm)
25"
(635 mm)
51-1/4"
(1302 mm)
22-1/2"
(572 mm)
Corner View
4"
(102 mm)
Electrical
Junction
Box
(On Right
Side)
2 x 4
Electrical
Junction
Box
31-1/4"
(794 mm)
Front View
Right Side
23-1/2"
Top View
5/8"
1-1/8"
32"
28-1/4"
23-1/4"
27-1/8"
10-3/4"
9-1/2"
29-3/8"
29-7/8"
Figure 2
