NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
22
Air Shutter
Adjustment Lever
Venturi Tube
Arm
Pan Burner
Valve Access Side
of Fireplace
Firebox Subfloor
Figure 38
In Canada:
THE CONVERSION SHALL BE CAR-
RIED OUT IN ACCORDANCE WITH THE
REQUIREMENTS OF THE PROVINCIAL
AUTHORITIES HAVING JURISDICTION
AND IN ACCORDANCE WITH THE RE-
QUIREMENTS OF THE CAN/CSA-B149.1
INSTALLATION CODE.
LA CONVERSION DEVRA ÊTRE EF-
FECTUÉE CONFORMÉMENT AUX RE-
COMMANDATIONS DES AUTORITÉS
PROVINCIALES AYANT JURIDICTION
ET CONFORMÉMENT AUX EXIGENCES
DU CODE D'INSTALLATION CAN/CSA-
B149.1.
Gas conversion kits are available to adapt
your appliance from the use of one type of
gas to the use of another. These kits contain
all the necessary components needed to
complete the task including labeling that must
be affixed to ensure safe operation.
Kit part numbers are listed here and the
following steps detail the conversion pro-
cedure. Refer to the instructions provided
with the conversion kit when performing any
gas conversion.
GAS CONVERSION KITS
INSTALLATION INSTRUCTIONS
Step 1. TURN OFF THE GAS SUPPLY TO THE
APPLIANCE and disconnect power supply at the
circuit breaker. Ensure appliance is cold.
CAUTION: THE GAS SUPPLY SHALL BE
SHUT OFF PRIOR TO DISCONNECTING THE
ELECTRICAL POWER, BEFORE PROCEED-
ING WITH THE CONVERSION.
ATTENTION. AVANT D’EFFECTUER
LA CONVERSION, COUPEZ D’ABORD
L’ALIMENTATION EN GAZ, ENSUITE,
COUPEZ L’ALIMENTATION ÉLECTRIQUE.
Step 2. Remove the front glass door/frame.
See Figure 33.
a. Remove the control compartment door (see
Removing Control Compartment Door, Page
14).
c. Remove the glass panel enclosure (on valve
access side) - Locate the two (2) latches
at the top of the control compartment. To
disengage the two latches from the bottom
vee-flange of the glass enclosure panel, reach
for the handles located towards the back of
the latches and pull the handles down toward
the front of the appliance.
d. Swing the bottom of the door out and raise
it slightly to lift the top flange of the door
frame away from the appliance.
Step 3. Carefully remove the logs. Exercise
care so as not to break the logs.
Step 4. Referring to Figure 38, remove the
burner.
WARNING
This conversion kit shall be installed by a qualified service agency in accor-
dance with the manufacturer’s instructions and all applicable codes and
requirements of the authority having jurisdiction. If the information in these
instruction is not followed exactly, a fire, explosion or production of carbon
monoxide may result causing property damage, personal injury or loss of
life. The qualified service agency is responsible for the proper installation
of this kit. The installation is not proper and complete until the operation
of the converted appliance is checked as specified in the manufacturer’s
instructions supplied with the kit.The qualified service agency performing
this installation assumes responsibility for this conversion.
AVERTISSEMENT
Cette trousse de conversion doit être installée par un technicien agréé,
selon les instructions du fabricant et selon toutes les exigences et tous les
codes pertinents de l’autorité compétente. Assurez-vous de bien suivre
les instructions dans cette notice pour réduire au minimum le risque
d’incendie, d’explosion ou la production de monoxyde de carbone pouvant
causer des dommages matériels, des blessures ou la mort. Le tecnicien
agréé est responsable de l’installation de cette trousse. L’installation n’est
pas adéquate ni complète tant que le bon fonctionnement de l’appareil
converti n’a pas été vérifié selon les instructions du fabricant fournies avec
la trousse. Le fournisseur de service qualifié ayant réalisé l'installation
assume les responsabilités liées à la conversion.
Electronic Systems
Propane Gas To Natural Gas
Conversion Kits
Models Catalog No.
GCK-MP40EPN 26M65
Electronic Systems
Natural Gas To Propane Gas
Conversion Kits
Models Catalog No.
GCK35STENP H3361
Millivolt SIT Systems
Propane Gas to Natural Gas
Conversion Kits
Models Catalog No.
GCK-MPB40MPN H2014
Millivolt SIT Systems
Natural Gas To Propane Gas
Conversion Kits
Models Catalog No.
GCK35STMPN H3360
