13
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS CONTINUED
Tall Arch Pane Door
Style View Doors Continued -
Style View Doors also come in a Tall Arch Pane Design. Two distinctive grille kits, the “Crescents” and “Sunrise” design, are
also offered seperately. They are easy to install and will not require hardware to attach them to the standard glass door frame.
The door includes heavy duty magnet door latches and functional twin-pane doors.
“Crescents” Grille Kits
“Sunrise” Grille Kits
TALL ARCH PANE DOORS
Cat. No. Model Description Model Series
H3537 TAPD35EC 35” Elite Arch Pane Doors, Charcoal
EDV3530
H3539 35” Elite Arch Pane Doors, Satin Pewter
40” Arch Pane Doors, Charcoal
EDV4035
40” Arch Pane Doors, Satin Pewter
45” Arch Pane Doors, Charcoal
EDV4540
45” Arch Pane Doors, Satin Pewter
TAPD35ESP
H3529 TAPD40C
H3531
TAPD40SP
H3533 TAPD45C
H3535
TAPD45SP
“Crescents” Grille Kits
Cat. No. Model Description Model Series
H3541 CUGK35C 35” Crescents Upper Grille Kit, Charcoal
EDV3530
H3543
35” Crescents Upper Grille Kit, Satin Pewter
CUGK35SP
H3545 CLGK35C 35” Crescents Lower Grille Kit, Charcoal
H3547
35” Crescents Lower Grille Kit, Satin Pewter
CLGK35SP
H3549 CUGK40C 40” Crescents Upper Grille Kit, Charcoal
EDV4035
H3551
40” Crescents Upper Grille Kit, Satin Pewter
CUGK40SP
H3553 CLGK40C 40” Crescents Lower Grille Kit, Charcoal
H3555
40” Crescents Lower Grille Kit, Satin Pewter
CLGK40SP
H3557 CUGK45C 45” Crescents Upper Grille Kit, Charcoal
EDV4540
H3559
45” Crescents Upper Grille Kit, Satin Pewter
CUGK45SP
H3561 CLGK45C 45” Crescents Lower Grille Kit, Charcoal
H3563
45” Crescents Lower Grille Kit, Satin Pewter
CLGK45SP
“Sunrise” Grille Kits
Cat. No. Model Description Model Series
H3565 SUGK35C 35” Sunrise Upper Grille Kit, Charcoal
EDV3530
H3567
35” Sunrise Upper Grille Kit, Satin Pewter
SUGK35SP
H3569 SLGK35C 35” Sunrise Lower Grille Kit, Charcoal
H3571
35” Sunrise Lower Grille Kit, Satin Pewter
SLGK35SP
H3573 SUGK40C 40” Sunrise Upper Grille Kit, Charcoal
EDV4035
H3575
40” Sunrise Upper Grille Kit, Satin Pewter
SUGK40SP
H3577 SLGK40C 40” Sunrise Lower Grille Kit, Charcoal
H3579
40” Sunrise Lower Grille Kit, Satin Pewter
SLGK40SP
H3581
SUGK45C 45” Sunrise Upper Grille Kit, Charcoal
EDV4540
H3583
45” Sunrise Upper Grille Kit, Satin Pewter
SUGK45SP
H3585 SLGK45C 45” Sunrise Lower Grille Kit, Charcoal
H3587
45” Sunrise Lower Grille Kit, Satin Pewter
SLGK45SP
This screen panel kit can be installed on the glass enclosure panel to prevent direct contact with the
hot glass surface. The panel kit adds a new design choice with a handsome textured iron finish. The
screen panel kit cannot be used in conjunction with either of the arch door kits or door frame kits.
Arch Screen Panel Kit Model No. Catalog No.
40" Decorative Arch Screen Panel Kit - Textured Iron DASPK40TI H3594
