NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Product Reference Information
Cat. No. Model Ship.
Weight
Ship.
Volumn
H0721 EDVSTNM 282 lbs. (36.2 cu.ft.)
H0722 EDVSTNE 282 lbs. (36.2 cu.ft.)
H0723 EDVSTPM 282 lbs. (36.2 cu.ft.)
H0724 EDVPFNM 270 lbs. (36.2 cu.ft.)
H0725 EDVPFNE 270 lbs. (36.2 cu.ft.)
H0726 EDVPFPM 270 lbs. (36.2 cu.ft.)
H0727 EDVCLNM 272 lbs. (36.2 cu.ft.)
H0728 EDVCLNE 272 lbs. (36.2 cu.ft.)
H0729 EDVCRNM 272 lbs. (36.2 cu.ft.)
H0730 EDVCRNE 272 lbs. (36.2 cu.ft.)
H0731 EDVCLPM 272 lbs. (36.2 cu.ft.)
H0732 EDVCRPM 272 lbs. (36.2 cu.ft.)
Deluxe Remote Control System
The Model RCL-T (Deluxe) Remote Control System
has all of the features of the standard system along
with an added easy to read LCD screen which presents
access to many enhancements, including; battery
power level indicator, timer, mode of operation,
thermostatic display including room temperature in
either metric of English units, flame indicator and
clock. Fully programmable, the Model RCL-T allows
for virtual command over nearly all operational and
temperature variables, using the hand held remote
control transmitter.
The Model RCL-T (Deluxe) remote control system
is installed in the same manner as the standard
system, may be operated with electronic and mil-
livolt systems with either natural gas or propane gas.
The RCL-T comes complete with detailed operating
instructions.
ACCESSORY COMPONENTS
Standard Remote Control System
The Model RCL (Standard) Remote Control System,
features a simplistic OFF/ON control function for the
fireplace. This model includes a hand-held transmitter,
a remote receiver with wall-mount cover plate and
all hardware required to install the unit. The remote
receiver can be wall or hearth mounted.
The transmitter has ON and OFF functions that are
activated by pressing either button on the face of
the transmitter. When a button on the transmitter
is pressed, a signal light illuminates briefly to verify
that a signal has been sent.
The Model RCL is designed to operate with all mil-
livolt ignition systems, as well as electronic ignition
systems. It may be installed with use for either
natural gas or propane gas appliances. The RCL
offers ease of installation and allows you to execute
on-off commands to the fireplace effortlessly with
one simple motion.
The Model RCL comes complete with detailed operat-
ing instructions.
Remote Control Kit, Standard
Cat. No. Model No. Description
H0249 RCL Remote Control System
(Standard)
Remote Control Kit, Deluxe
Cat. No. Model No. Description
H0251 RCL-STAT Remote Control System
(Deluxe)
Forced Air Kit
The FBK-100 blower provides constant velocity forced
air circulation. The FBK-200 assembly with variable
speed, wall-mountable switch provides variable speed
forced air circulation. The FBK-250 assembly with
variable speed unit-mountable switch, also provides
variable speed forced air circulation.
Forced Air Blower Kits
Cat.
No.
Model No. Description
80L84 FBK-100 Blower, Standard
(single speed)
80L85 FBK-200 Blower, Variable Speed
(w/wall-mounted switch)
80L86 FBK-250 Blower, Variable Speed (w/
unit-mounted switch)
94L89 FBK-100-36 Blower, Standard, 36 Pack
94L90 FBK-200-36 Blower Kit - Variable Speed
with Wall Switch 36 Pack
H0543 FBK-250-36 Blower Kit - Variable Speed
with Thermo Snap Switch
36 Pack
Flame Modulating Remote Control
Flame Modulating Remote Controls were devel-
oped to provide a safe, reliable and user-friendly
remote control system for appliances equipped
with a Millivolt Gas Valve. A detailed set of
instructions are included with each remote.
Flame Modulating Remote Control
– Natural Gas H0301 RCL-MN
Flame Modulating Remote Control
– LP/Propane Gas H0302 RCL-ML
