Crevice and brush tool
accessories
The crevice tool is ideal for vacuuming
hard to reach places such as the edges
along skirting boards.
The brush tool can be used to vacuum
delicate surfaces and areas such as shelves
and venetian blinds.
For models with Variable Power Control,
set between Minimum and Medium power
when using the tool accessories.
For models without Variable Power
Control, slide the Fingertip Suction
Control cover (located on the hose
handle) to the open position.
Models KVC12/KVC15 and KVC16
Separate crevice and brush tools are
located inside the on-board tool storage
compartment.The opening for this
compartment is located directly below the
hose connection inlet.To open place a
finger inside the thumb groove and pull
the compartment lid upwards.
Model KVC11 only
The crevice tool with detachable
brush attachment can be stored
on the wand attachment for easy
access and storage.
To use the crevice tool, detach
the brush attachment from the
top to reveal the crevice tool.When the
brush attachment is required, push the back
onto the top of the crevice tool until it is
firmly in place.
T
urn off the vacuum when changing an
y
attachments.
Using the Park Tool feature
The vacuum features a 2-way park tool
feature, which allows you to easily store
the wands with the floor tool directly on
the vacuum body.This is ideal when storing
the vacuum or if you need to temporarily
‘park’ the vacuum while you are cleaning.
To park the vacuum in the
upright (storage) position
The park tool attachment
hook, for upright storage is
located on the lower wand.
With the vacuum switched off
and unplugged from the power point, place
the vacuum on its end (in an upright
position), insert the park tool hook into
the park tool receptacle on the underside
of the vacuum body (located to the upper
right of the front
wheel).
Note:The floor tool should
be attached and in contact
with the floor to give
stability, if correctly
assembled.
To park the vacuum
in the horizontal position
The park tool attachment hook, to park
the vacuum in the horizontal position, is
located on the floor tool head (on the
wand connection point).
With the vacuum on the floor in a
horizontal position, hold the floor tool
head facing outwards
and insert the park
tool hook into the
park tool r
eceptacle
located at the rear of
the unit.
