IM-AS/02.00 GB (0412)
12.0 Spare parts lists and sectional drawings
12.1 Spare part list AS 40, 50, 60-65, 80
Pos Qty Description Material
11Casing, pump CF-3M / 1.4409
1 Q 1 Casing, pump Q-execution CF-3M / 1.4409
1 V 1 Casing, pump V-execution CF-3M / 1.4409
21Cover, casing CF-3M / 1.4409
31Impeller CF-3M / 1.4409
41Shaft AISI 316 L / 1.4404
4 V 1 Shaft V-execution AISI 316 L / 1.4404
51Housing, bearing Cast iron 25 + 3%Ni
61Mechanical seal -
6 Q 1 Mechanical seal, Q-execution -
71Bearing Steel
81Bearing cover Aluminum 2011
91Clamp, casing AISI 304 / 1.4301
10 1 Nut, impeller AISI 316 L / 1.4404
11 1 Key, impeller AISI 316 / 1.4401
12 1 Pin AISI 304 / 1.4301
13 1 O-ring EPDM
14 1 Thrower NBR
15 1 Shaft plug NBR
16 1 O-ring EPDM
17 1 Nut, ring Galvanized iron
18 1 Grease nipple Galvanized iron
19 2 Shim AISI 316 L / 1.4404
20 1 Foot, front CF-8 / 1.4308
21 2 Foot, adjustable AISI 304 / 1.4301
23 1 Foot, rear CF-8 / 1.4308 - AISI 304 / 1.4301
25 1 Foot, adjustable AISI 304 / 1.4301
26 4 Screw, socket head AISI 304 / 1.4301
27 3 Screw, socket head AISI 304 / 1.4301
28 4 Screw, hex-head Steel
29 2 Screw, socket head AISI 304 / 1.4301
30 2 Nut AISI 304 / 1.4301
33 1 Gaco-ring NBR
40 2 Lantern guard AISI 304 / 1.4301
43 1 Shroud, adapter AISI 304 / 1.4301
44 1 Shroud AISI 304 / 1.4301
45 3 Screw, hex-hollow AISI 304 / 1.4301
46 3 Screw, flat head AISI 304 / 1.4301
50 1 Motor-electric -
60 Q 1 Mechanical seal cover Q-execution AISI 304 / 1.4301
61 Q 1 O-ring Q-execution NBR
62 Q 2 Screw, hex-head Q-execution AISI 304 / 1.4301
65 V 1 Mechanical seal cover V-execution AISI 304 / 1.4301
66 V 1 Seal, radial shaft V-execution -
68 Q 2 Stud bolt Q-execution AISI 304 / 1.4301
68 V 2 Stud bolt V-execution AISI 304 / 1.4301
70 V 1 O-ring V-execution NBR
71 Q 2 Mechanical seal flushing pipe Q-execution AISI 304 / 1.4301
71 V 2 Mechanical seal flushing pipe V-execution AISI 304 / 1.4301
85 V 1 Ceramic hardened bush V-execution AISI 304 / 1.4301
86 V 1 O-ring V-execution NBR
87 V 3 Dowel V-execution AISI 304 / 1.4301
