No. in
explode
d view
Spare parts
number
Spare parts description in english Model QTY
.
Failure
rate
The proportion
of the spare part
stock
remark
1 001A0100017 Front grille HSU-09HS03/R2(DB) 1
2 001A1101009 Front panel HSU-09HS03/R2(DB) 1
3 0010203662 Fan HSU-09HS03/R2(DB) 1 *
4 0010403487 Motor HSU-09HS03/R2(DB) 1 *
5 0010100419 Frame for motor HSU-09HS03/R2(DB) 1
6 0010706498 Heat exchanger HSU-09HS03/R2(DB) 1
7 001A5736055
Fixed clip forenviroment temp.
sensor
HSU-09HS03/R2(DB) 1
8 001A3800082 Temperature sensor HSU-09HS03/R2(DB) 1 *
9 0010101388 Back panel HSU-09HS03/R2(DB) 1
10 001A1101010 Top panel HSU-09HS03/R2(DB) 1
11 001A3900056 Compressor temperature sensor HSU-09HS03/R2(DB) 1 *
12 001A3900055 Tube temperature sensor HSU-09HS03/R2(DB) 1 *
13 0010706509 Entering gas pipe HSU-09HS03/R2(DB) 1
14 0010706497 Capillary Tube HSU-09HS03/R2(DB) 1
15 0010403022 4-way valve coil HSU-09HS03/R2(DB) 1 *
16 0010704488 4-way valve HSU-09HS03/R2(DB) 1
17 0010705988 Stop valve HSU-09HS03/R2(DB) 1
18 0010705255 Stop valve HSU-09HS03/R2(DB) 1
19 001A5102050 Flange Nut HSU-09HS03/R2(DB) 3
20 0010706492 Compressor HSU-09HS03/R2(DB) 1 *
21 001A17621544 Cushion HSU-09HS03/R2(DB) 1
22 001A1101014 Bottom plate HSU-09HS03/R2(DB) 1
23 001A1436042 Service cover HSU-09HS03/R2(DB) 1
24 0010804196 Separating plate HSU-09HS03/R2(DB) 1
25 001A0100427 Reactor box HSU-09HS03/R2(DB) 1
26 0010403365 Reactor HSU-09HS03/R2(DB) 1 *
27 0010403368 Power Module HSU-09HS03/R2(DB) 1 *
28 0010403521 PCB HSU-09HS03/R2(DB) 1 *
29 0010403520 Capacitor board HSU-09HS03/R2(DB) 1 *
30 001A4000105 Terminal Block HSU-09HS03/R2(DB) 1
1,The failer rate and the proportion of the spare-part stock are regarded as the reference of the stock for spare-parts;The first
time should be stocked accroded with the proportion of the spare-parts,and it should be adjusted with the actual quantity 3
months later.
2,easy-damaged;The spare-part which is often damaged and the customer must stock in the spare-parts warehouse,and
should be marked with"*"
3,possible damaged:The spare-part which is not often damaged like the easy damaged one and the customer may stock in
the spare-part warehouse accord with the actual case,should be marked with " ".
4,not need provided :The spare-part which is seldom damaged or the maintenance man could not maitmains.The spare
parts may be air freighted by the factory if they were damaged.The customer nees not stock in the spare-part
warehouse,should be marked with " x ".
5,Above should be improved accord with the reply of the market half a year per time.
6.The spare parts price on net is FOB Qingdao term.
Model:
Edition:2004/10/26
HSU-09HS03/R2(DB)Domestic Air Conditioner
20
