pRodUCt SpECifiCationS
pRodUCt SpECifiCationS
2 www.goodmanmfg.com SS-GPH13MC
SS-GPH13MC www.goodmanmfg.com 3
SpECifiCationS
GPH13
36M43**
GPH13
48M43**
GPH13
60M43**
Total BTU/h 34,000 48,000 57,500
Sensible BTU/h 24,140 36,800 40,800
SEER / EER 13/10.8 13/11.5 13/11
Decibels 80 80 80
AHRI #s 4385123 4385128 4385131
BTU/h (47°F) 33,800 46,500 57,000
COP (47°F) 3.4 3.7 3.4
BTU/h (17°F) 19,200 27,000 31,200
COP (17°F) 2.2 2.3 2.2
HSPF 7.7 8.0 8.0
Type DD EEM EEM
Wheel (DxW) 10 x 9 10 x 9 10 x 9
Nominal Cooling CFM 1,050 1,720 1,800
Indoor Blower FLA / LRA 3.06 / 4.1 5.8 / -- 7.6 / --
No. of Speeds 3 5 5
Horsepower - RPM ⅓ - 910 ¾ - 1,050 1 - 1,050
Face Area (²) 4.52 6.17 6.17
Rows Deep/ Fins per Inch 4 / 14 4 / 14 4 / 14
Drain Size (NPT) ¾" ¾" ¾"
Refrigerant Charge (oz) 141 205 220
Horsepower - RPM ¼ - 830 ¼ - 1,075 ¼ - 1,075
Oudoor Fan FLA / LRA 1.5 / 3.0 1.4 / 2.9 1.4 / 2.9
Fan Diameter / # Fan Blades 22/4 22/3 22/3
Face Area (²) 16.83 19.24 21.04
Rows Deep/Fins per Inch 1 / 22 2 / 16 2 / 16
Quanty / Type 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single
Compressor RLA/LRA 10.4 / 73 13.7 / 83.1 16.0 / 110
Voltage/ Phase/ Hz 208-230/3/60 208-230/3/60 208-230/3/60
Total Unit Amps 15.0 21.0 25.0
Min. Circuit Ampacity¹ 17.6 24.3 29.0
Max. Overcurrent Protecon² 25 amps 35 amps 45 amps
419 531 542
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
