Goodman Mfg GKS90703BXAB Furnace User Manual



Cabinet
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
NAMEPLATE, GOODMAN 0161F00000P21
DRAIN HOSE 2020190281
GASKET (QTY 2)20179308111
GASKET (M1, M2, M3, M4, M5, M6, M7, M8)20194605121
GASKET (M9, M10, M11, M12, M13, M14, M15,
M16)
20194606121
GASKET (M17, M18, M19, M20, M21, M22, M23)20194607121
ACCESS DOOR (M1, M2, M3, M4, M5, M6, M7, M8)0121F00072DGS191
ACCESS DOOR (M9, M10, M11, M12, M13, M14,
M15, M16)
0121F00073DGS191
ACCESS DOOR (M17, M18, M19, M20, M21, M22,
M23)
0121F00074DGS191
BLOWER DOOR (M1, M2, M3, M4, M5, M6, M7, M8)0121F00069DGS201
BLOWER DOOR (M9, M10, M11, M12, M13, M14,
M15, M16)
0121F00070DG201
BLOWER DOOR (M17, M18, M19, M20, M21, M22,
M23)
0121F00071DG201
VIEW PORT BUSHING-BLOWER DOOR B1392139281
VIEW PORT BUSHING-ACCESS DOOR (M1, M2,
M4, M5, M9, M10, M12, M13, M17, M18, M20, M21)
11104002291
VIEW PORT BUSHING-ACCESS DOOR (M3, M6,
M7, M8, M11, M14, M15, M16, M19, M22, M23)
B1392139291
DECK GASKET (M1, M2, M3, M4, M5, M6, M7, M8)22320001311
DECK GASKET (M9, M10, M11, M12, M13, M14,
M15, M16)
22320002311
DECK GASKET (M17, M18, M19, M20, M21, M22,
M23)
22320003311
PIPE GROMMET M0501301451
BUTTON PLUG (QTY 4)M0570808491
PLUG-BUTTON M0570806501
BUTTON PLUG M0570807511
GROMMET (QTY 2)A4691701601
BUTTON PLUG (QTY 2)M0310345621
UNIVERSAL BUSHING UB 875 (QTY AR)B1392104741
STANDPIPE BAG ASSY 0270F00399NS
WIRING HARNESS 0159F00003NS
Image 2:
RUBBER COUPLING 1025430312
HOSE CLAMP (QTY 2)0163M0004922
HOSE CLAMP M011920732
DRAIN HOSE 2020190162
DRAIN TUBE (QTY 2)2020180272
DRAIN TRAP 2017170182
DRAIN ANGLE 20214203112
HOSE CLAMP (QTY 3)M0119205142
HOSE CLAMP M0119206172
Expanded Model Nomenclature
M1 - GKS90453BXAA
M2 - GKS90453BXAB
M3 - GKS90453BXAC
M4 - GKS90703BXAA
M5 - GKS90703BXAB
M6 - GKS90703BXAC
M7 - GKS90703BXAD
M8 - GKS90703BXAE
M9 - GKS90704CXAA
M10 - GKS90704CXAB
M11 - GKS90704CXAC
M12 - GKS90904CXAA
M13 - GKS90904CXAB
M14 - GKS90904CXAC
M15 - GKS90904CXAD
M16 - GKS90904CXAE
M17 - GKS90905DXAA
M18 - GKS90905DXAB
M19 - GKS90905DXAC
M20 - GKS91155DXAA
M21 - GKS91155DXAB
M22 - GKS91155DXAC
M23 - GKS91155DXAD
5
RP-410F
