Functional Parts
Part
No:
Description:
B1340024S BLOWER MOTOR 1/2 HP, 4 SP, 6 PL (M9,
M10, M11, M12, M13, M14, M15, M16)
0131F00020 BLOWER MOTOR 1/3 HP, 4 SP, 6 PL (M1, M2,
M3, M4, M5, M6, M7, M8)
10759415S BLOWER MOTOR 3/4 HP, 4 SP, 8 PL (M17,
M18, M19, M20, M21, M22, M23)
CAP125000370VAS CAPACITOR 12.5/370V (M1, M2, M3, M4, M5,
M6, M7, M8)
CAP150000370VAS CAPACITOR 15/370V (M17, M18, M19, M20,
M21, M22, M23)
CAP200000370VAS CAPACITOR 20/370V (M9, M10, M11, M12,
M13, M14, M15, M16)
0130F00010 FLAME SENSOR
0130F00005S IGNITION BOARD, HSI INTEGRATED
20165703S IGNITOR
B1370818 INTERLOCK SWITCH
10123535 MANUAL RESET LIMIT (M1, M2, M3, M4, M5,
M6, M7, M8, M9, M10, M11, M12, M13, M14,
M15, M16, M17, M18, M19)
10123533 MANUAL RESET LIMIT
20197312 PRESSURE SWITCH-LIGHT BLUE (M1, M9,
M17)
0130F00002P PRESSURE SWITCH-OLIVE (M16)
20197310 PRESSURE SWITCH-ORANGE (M12, M20)
0130F00004 PRESSURE SWITCH-RED (M4, M18, M19)
0130F00001P PRESSURE SWITCH-SUNGOLD (M2, M3, M5,
M6, M7, M8, M10, M11, M13, M14, M15, M21,
M22, M23)
20162903 PRIMARY LIMIT-BLUE (M4, M5, M6, M7, M8,
M9, M10, M11, M17, M18, M19)
20162904 PRIMARY LIMIT-TEMPERATURE CONTROL
(M1, M2, M3, M12, M13, M14, M15, M16)
20162906 PRIMARY LIMIT-WHITE (M20, M21, M22, M23)
B1141605 TRANSFORMER 120V TO 24V, 40 VA
SPECIAL PARTS
IO-300E INSTALLATION INSTRUCTIONS
IO-669 KIT INSTRUCTIONS-HUMIDIFIER
0161F00000P NAMEPLATE, GOODMAN
RP-410F REPAIR PARTS MANUAL
IO-661 SPECIAL INSTRUCTIONS-
MASSACHUSETTS
0270F00399 STANDPIPE BAG ASSY
HI-115A USERS MANUAL
Expanded Model Nomenclature
M1 - GKS90453BXAA
M2 - GKS90453BXAB
M3 - GKS90453BXAC
M4 - GKS90703BXAA
M5 - GKS90703BXAB
M6 - GKS90703BXAC
M7 - GKS90703BXAD
M8 - GKS90703BXAE
M9 - GKS90704CXAA
M10 - GKS90704CXAB
M11 - GKS90704CXAC
M12 - GKS90904CXAA
M13 - GKS90904CXAB
M14 - GKS90904CXAC
M15 - GKS90904CXAD
M16 - GKS90904CXAE
M17 - GKS90905DXAA
M18 - GKS90905DXAB
M19 - GKS90905DXAC
M20 - GKS91155DXAA
M21 - GKS91155DXAB
M22 - GKS91155DXAC
M23 - GKS91155DXAD
3
RP-410F
