Operating Instructions
Operating Instructions
(continued)
CHECK FILTER FEATURE, YOU WILL SEE:
2009 Electrolux Home Products, Inc. All rights reserved.
DO THIS:
PRESS FILTER
RESET BUTTON
TIMER: DELAY STOP / START FEATURE YOU WILL SEE HOW MUCH TIME IS CHOSEN:
Note: For Delay Stop, the unit must be in the On position
Note: For Delay Start, the unit must be in the Off position.
FIRST
DO THIS:
PRESS
TIMER BUTTON
THEN
DO THIS:
Note: This feature is a reminder to clean the Air Filter (See
Care and Cleaning) for more efficient operation. The LED
(light) will illuminate after 250 hours of operation. To reset
after cleaning the filter, press the "Filter Reset" button and
the light will go off.
If the display reads "AS" , a sensor has failed. Contact your
Authorized Frigidaire Service Center.
If the display reads "ES" , a sensor has failed. Contact your
Authorized Frigidaire Service Center.
FAULT CODES:
First, Press TIMER button, then adjust timer setting, tap or
hold the UP arrow ( ) or the DOWN arrow ( ) to
change delay timer at 0.5 hour increments, up to 10 hours,
then at 1 hour increments up to 24 hours. The control will
count down the time remaining until start (8, 7.5, 7, etc.).
The Delay Start Operation automatically selects cooling with
maximum Fan speed (if Cool, Energy Saver, or Fan Only was
the last mode selected) . The temperature maintained will
be the same as previously set. To change the set tempera-
ture, press "COOL" then Up or Down arrows until the de-
sired temperature is indicated on the display. After 5 se-
conds, the control will automatically change the display back
to the hours remaining until the unit will start/stop. Pressing
the unit On/Off button at any time will cancel the Delay
Start/Stop function. The Delay Start/Stop Feature will work
until the unit either starts or stops. Once that happens the
above steps have to be repeated again.
PRESS
UP/DOWN
SET BUTTONS
