CMY Zoom 575™
©Elation Professional® 25 CMY Zoom 575™
will test the color channel, changing the color one by one and show the rainbow
effect with different speeds. Again please remember, there are 10 DMX channels,
and all except channels 3, 6, and 10 can be tested
4. Press MODE/ESC to exit.
2. PLAY MENU -
RUN
– This feature is used to run the internal preset programs in either a Master/Slave
or a stand-alone operating mode. Follow the procedure below to enter the run menu:
1. Access the main menu.
2. Tap the UP or DOWN button until “PLAY” is displayed, press ENTER.
3. Tap the UP or DOWN button until “RUN” is displayed, press ENTER.
4. Tap the UP or DOWN button to select either “Master” or “Alone” and press ENTER.
5. Press MODE/ESC to return to the main menu.
AUDI
- This feature is used to run the internal preset programs in AUDIO mode in either
a Master/Slave or a stand-alone operating mode Follow the procedure below to enter the
audio menu:
1. Access the main menu.
2. Tap the UP or DOWN button until “PLAY” is displayed, press ENTER.
3. Tap the UP or DOWN button until “AUDI” is displayed, press ENTER.
4. Tap the UP or DOWN button to select either “Master” or “Alone” and press ENTER.
5. Press MODE/ESC to return to the main menu.
AUTO
– Runs the unit without any DMX signal in stand-alone mode. Follow the procedure
below to enter the auto menu:
1. Access the main menu.
2. Tap the UP or DOWN button until “PLAY” is displayed, press ENTER.
3. Tap the UP or DOWN button until “AUTO” is displayed, press ENTER.
