EdgeStar PAC8000S Air Conditioner User Manual



The power button controls the
power to the unit.
In the cooling mode, room air is cooled and hot
air is exhausted to the outside through the air
exhaust hose. Adjust the fan speed and
temperature to suit your desired comfort level.
Note: The air exhaust hose must be vented
through a window when using the cooling mode
(see the page titled Installation for more detail).
The dehumidifying mode removes water from the
air without cooling the room. If the room tempera-
ture is below 77ºF, the fan speed will be locked on
“low;” above 77ºF, the fan speed is adjustable.
Note: The exhaust hose is not required in
dehumidifying mode. Note that the internal
water tray will fill with water in this mode.
To set the temperature in cooling mode, use the up
“▲” and down “▼” buttons. The temperature setting
range is from 61
°
F- 89
°
F.
Note: When in dehumidifying or fan mode,
temperature setting is not required or allowed.
°
F
Note: Inital setting is in
°
F
The settings are toggled by the mode button
Note: All functions on this portable air
conditioner are controlled by the
remote. This remote accepts AAA
batteries
s
This unit has 3 settings:
ing
(Blue light)
Note: The unit does not need to be vented in
fan mode.
This unit has 3 fan speeds: High, Medium and
Low. Press the speed button to toggle the speeds.
Note: Fan speeds will not be displayed on the
control panel.
Temperature
Pressing this button will switch the temperature
read-out between ºC and ºF.
Setting the Timer
Cancelling the Timer
You may cancel the timer setting at any time by
pressing the cancel button or by pressing the
power button.
If the unit is on:
• Press the timer button.
• Use the up “▲” and down “▼” buttons to select a
time (displayed in hours).
• After the selected time elapses, the unit will
automatically shut off.
If the unit is off:
• Press the timer button.
• Use the up “▲” and down “▼” buttons to select a
time (displayed in hours).
• Then select which mode you want the unit to
automatically start in and make the necessary
adjustments.
• After the selected time elapses, the unit will
automatically turn on.
Note: The timer setting range is between 1 and
24 hours.
Operation
Mode Light
The light on the display panel on the portable air conditioner
changes color to indicate the mode (see next page for
more information):
• Blue: When the light is blue, the unit is in cooling mode.
• Orange: When the light is orange, the unit is in dehumidifying
mode.
• Green: When the light is green, the unit is in fan mode.
Air is circulated throughout the room. The compressor
does not turn on, so no air conditioning takes place.
Cooling
Cooling Mode
Fan Speed
Fan Mode (Green light)
Power control
Dehumidifying Mode (Orange light)
Fahrenheit/Celsius
