Dimplex DF3015 Indoor Fireplace User Manual



PURIFIRE™ FILTER
The Purifire™ filter supplied in your fireplace is reusable and washable. The filter should be
cleaned or replaced on average once a year. To clean the filter gently tap filter on a hard
surface to dislodge any loose dirt or debris, and then clean with water. No soap or cleaning
products are recommended. The filter size is 20” X 10” X 1” rated at MERV 10. If using an
after market filter follow the manufacturers recommended replacement instructions.
To replace filter:
1. Remove fireplace from mantel.
2. Filter can be accessed from the top rear of the unit.
3. Grasp filter and slide filter straight up.
4. Replace or clean filter.
NOTE
If after market air filter is used ensure it is installed according to the manufacturers
recommended instructions.
GLASS CLEANING
The glass is cleaned in the factory during the assembly operation. During shipment,
installation, handling, etc., the glass may collect dust particles; these can be removed by
dusting lightly with a clean dry cloth.
To remove fingerprints or other marks, the glass can be cleaned with a damp cloth. To
prevent scratching, do not use abrasive cleaners or spray liquids on the glass surface.
FIREPLACE SURFACE CLEANING
Use a cloth dampened with warm water only to clean painted surfaces of the electric fireplace.
Do not use abrasive cleaners.
Air Filter
FIGURE 9
