Deltaco 50-868 Air Cleaner User Manual



8
Fig. 7A
USING THE
REMOTE CONTROL
To reduce the risk of fire or electric
shock, do not use this unit with any solid-state speed
control device. The remote control provided with this
unit is not considered a solid-state device.
The Air Cleaner is equipped with a REMOTE CONTROl
(A) Fig.7A. NOTE: The remote requires two (2) AAA
batteries (not supplied). Battery housing is located
inside the back cover.
Notice that the remote control has three control buttons
(Fig. 7A): TIME (B), ON/OFF (C), and SPEED (D). These
buttons correspond to the LED sensor panel on the rear
of the machine (I) Fig. 7B. NOTE: When the machine is
connected to the power source, a green light (E) will
be activated on the panel.
To activate the blower unit, press the “ON/OFF” button
(C) Fig. 7A. The machine will begin in the default speed
of Low or “L” on the sensor panel. Press the SPEED but-
ton once, and the machine will run at the high (or “H”
level). Press the SPEED button again, and the machine
will run at the medium speed (or “M”). Press the SPEED
button a third time, and the machine will return to the
Low Speed mode.
To turn the machine off, press the “ON/OFF” button (C)
Fig. 7A.
A
B
Fig. 7B
The 50-868 Dust Collector provides a timer that can be
set by remote control. (B) Fig. 7A.
When the TIME button (B) Fig. 7A is pressed on the
remote control, the machine will run for 1/2 hour. (An
LED light will show up on the sensor panel (F) Fig. 7B).
Pressing the TIME button again will set the machine to
run for one hour. Notice that the light on the sensor
panel has now moved to the 1H location (G) Fig. 7B.
When the TIME button is pressed a third time, the
machine will run for 90 minutes. At this point, two lights
will appear - one under the 1H location (G) and one
under the 1/2H location (F) indicating an hour and a
half.Continue this process for up to 7 1/2 hours of run
time.
All of these actions can be manually controlled by using
the buttons on the sensor panel (I) Fig. 7B.
C
E
F
G
I
H
D
The Delta 50-868 air cleaner can be used in
a. bench-top sanding applications.
b. circular saw applications
c. dry wall applications
d. shop cleaning applications
e. floor sanding applications.
f. any other application where non-metallic dust is a factor.
OPERATIONS
1. NOTE: The air cleaner may produce a slight odor for the first few hours of operation due to the protective coating
which is applied to internal components. This odor will dissipate and should be disregarded. IMPORTANT: Never
operate the air cleaner without air filters in place.
