iLux™ Expansion Module Crestron CLS-EXP-DIMU
CLS-EXP-DIMU Specifications (continued)
CLS-EXP-DIMU Specifications (continued)
SPECIFICATION DETAILS
Enclosure Surface mount module with (2)
integral mounting flanges,
galvanized steel w/gray matte
powder coat front panel,
extruded aluminum heat sink, ½”
and ¾” conduit knockouts
provided on bottom and lower
left & right sides
Environmental
Temperature
Humidity
Heat Dissipation
32° to 104°F (0° to 40°C)
10% to 90% RH
(non-condensing)
200 BTU/Hr at maximum load
SPECIFICATION DETAILS
Dimensions
Height
Width
Depth
Weight
8.82 in (22.40 cm)
6.39 in (16.23 cm)
3.18 in (8.08 cm)
3.34 lbs (1.52 kg)
Compatible Control
Devices
CLS(I)-C6 Series
CLW-DIM Series
CLW-DIMXRF Series
CLX(I)-1DIM4
CLX-1DIM8
CLX(I)-2DIM2
CLX(I)-2DIM8
DIN-1DIMU4
iLux Integrated Lighting System
Wall Dimmers
infiNet™ Wall Dimmers
Four Channel Dimmer Module,
Single Feed
Eight Channel Dimmer Module,
Single Feed
Two Channel Dimmer Module,
Two Feeds
Eight Channel Dimmer Module,
Two Feeds
DIN Rail Universal Dimmer
(Continued on following column.)
Industry Compliance
This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc. These devices have
been additionally evaluated to UL 2043, The Standard for Fire Test for Heat and Visible Smoke Release for Discrete
Products and Their Accessories Installed in Air-Handling Spaces.
(E103692)
As of the date of manufacture, the CLS-EXP-DIMU has been tested and found to comply with specifications for CE marking.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference and (2) this device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
2 • iLux™ Expansion Module: CLS-EXP-DIMU Installation Guide – DOC. 6682B
