J-Series Installation Instructions
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
Table 1: Parts
QUANTITY By
MODEL
ITEM DESCRIPTION JWP JWS JWD
A PIVOT PITCH WALL MOUNT 1 - -
B SINGLE ARM WALL MOUNT - 1 -
C DUAL ARM WALL MOUNT - - 1
D J-SERIES WALL PLATE 1 1 1
E CABLE MANAGEMENT COVER - 1 2
F HEX HEAD LAG SCREW, 3/8" X 3" 2 2 2
G PHILLIPS FLAT MACHINE SCREW, 8-32 X 3/8" - 2 4
1/8"
#2
A
B
C
D
E
F
G
Interface
Bracket
Kit
(Including Hardware)
x 1
x1
I/M
