Bard WL602N Air Conditioner User Manual



Manual 2100-351
Page 2
WALL MOUNT GENERAL INFORMATION
AIR CONDITIONING WALL MOUNT MODEL NOMENCLATURE
WL 60 2 3 A 10 X N X X X A
NOTE: All vent options are without exhaust capability. May require separate field supplied barometric relief in building.
TABLE 1
ELECTRIC HEAT TABLE
WL4822A, WL4822B, WL4823A, WL4823B, WL6022A, WL6022B are not
approved for use with electric heat.
sledoM
WK
YLNOA3206LWYLNOB3206LW
1-V0421-V8021-V0421-V802
SPMAHUTBSPMAHUTBSPMAHUTBSPMAHUTB
0.58.02050,711.81008,21------------
0.9------------7.12006,037.81030,32
0.016.14031,432.63006,52------------
MODEL NUMBER
CONTROL MODULES
CAPACITY
60 - 5 Ton
VOLTS & PHASE
A - 230/208/60/1
B - 230/208/60/3
REVISIONS
KW
VENTILATION OPTIONS
B - Blank-off Plate
FILTER OPTIONS
N - No Filter WL4823, WL6023, WL602N models ONLY
X - One Inch Throwaway Filter WL4822, WL6022 models ONLY
W - One Inch Washable Filter WL4822, WL6022 models ONLY
P - Two Inch Pleated Filter WL4822, WL6022 models ONLY
COLOR OPTIONS
X - Beige (Standard)
1 - White
2 - Mesa Tan
4 - Buckeye Gray
COIL OPTIONS
X - Standard
1 - Phenolic Coated Evaporator
2 - Phenolic Coated Condenser
3 - Phenolic Coated Evaporator
and Condenser
OUTLET OPTIONS
X - Front (Standard)
FEATURE CODE
3 - 3 ton air openings
on 5 ton cabinet
2 - 2 ton air openings
on 5 ton cabinet
Model WL602N is identical to Model WL6023. All references in this
manual to WL6023 apply to WL602N also.
