TH146-N-DE 400-280-000-G 9/22/06 8/8
2) Set the humidity level or offset using the buttons.
• humidity level: 5% to 60%
• offset: -9% to 9%
3) Press the button to exit.
The symbol is displayed when the humidifier is On.
The controller can be placed in unoccupied mode via a remote con-
trol device such as Aube’s CT241 telephone controller (see section
2.10). In this mode, the setpoint is set back by 4.5°C (8°F); it is low-
ered in heating mode or raised in cooling mode. The icon
appears during the unoccupied mode.
NOTE: Automatic changeover is disabled during the unoccupied
mode.
If you change the temperature setpoint (using the buttons) in
unoccupied mode, the controller temporarily bypasses the current
setpoint. The new setpoint will be maintained for 2 hours, after
which the controller will return to the previous setpoint. The icon
flashes during the bypass.
CT280-HP-2H1C Control Module
Power supply: 24 VAC
Current consumption: 150 mA
Maximum load per output: 1 A @ 24 VAC
Short cycle protection: 2 minutes
Control cycles: 2 to 6 per hour
Operating temperature: 0°C to 50°C (32°F to 122°F)
Storage temperature: -20°C to 50°C (-4°F to 122°F)
Humidity conditions: 0% to 95%, non-condensing
Dimensions: 76 mm x 109 mm x 25 mm (3 in. x 4.3 in. x 1 in.)
TH146 Console
Temperature setpoint range: 5°C to 30°C (40°F to 86°F)
Humidity setpoint range: 5% to 60%
Indoor temperature display range: 0°C to 70°C (32°F to 158°F)
Outdoor temp. display range: -50°C to 70°C (-58°F to 158°F)
Temperature display resolution: 0.5°C (1°F)
Program protection: non-volatile memory
Operating temperature: 0°C to 50°C (32°F to 122°F)
Storage temperature: -20°C to 50°C (-4°F to 122°F)
Humidity conditions: 0% to 95%, non-condensing
Dimensions: 79 mm x 79 mm x 24 mm (3.1 in. x 3.1 in. x 1 in.)
Aube warrants this product, excluding battery, to be free from
defects in the workmanship or materials, under normal use and
service, for a period of three (3) years from the date of purchase by
the consumer. If at any time during the warranty period the product
is determined to be defective or malfunctions, Aube shall repair or
replace it (at Aube's option).
If the product is defective,
(i) return it, with a bill of sale or other dated proof of purchase, to
the place from which you purchased it, or
(ii) contact Aube. Aube will make the determination whether the
product should be returned, or whether a replacement product
can be sent to you.
This warranty does not cover removal or reinstallation costs. This
warranty shall not apply if it is shown by Aube that the defect or
malfunction was caused by damage which occurred while the
product was in the possession of a consumer.
Aube's sole responsibility shall be to repair or replace the product
within the terms stated above. AUBE SHALL NOT BE LIABLE FOR
ANY LOSS OR DAMAGE OF ANY KIND, INCLUDING ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING,
DIRECTLY OR INDIRECTLY, FROM ANY BREACH OF ANY
WARRANTY, EXPRESS OR IMPLIED, OR ANY OTHER FAILURE
OF THIS PRODUCT. Some provinces and states do not allow the
exclusion or limitation of incidental or consequential damages, so
this limitation may not apply to you.
THIS WARRANTY IS THE ONLY EXPRESS WARRANTY AUBE
MAKES ON THIS PRODUCT. THE DURATION OF ANY IMPLIED
WARRANTIES, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, IS HEREBY LIMITED TO THE THREE-YEAR
DURATION OF THIS WARRANTY. Some provinces and states do
not allow limitations on how long an implied warranty lasts, so the
above limitation may not apply to you.
This warranty gives you specific legal rights, and you may have
other rights which vary by province, state or region.
If you have any questions about the product installation or
operation, or concerning the warranty, contact us at the address
shown below.
For more information on our products, visit us at:
www.aubetech.com
5.6
Unoccupied Mode
5.7
Temporary Bypass
6. Technical Specifications
Humidity
level set
by user
Offset set
by user
Humidity level
set by controller
7. Warranty
8. Support
705 Montrichard
Saint-Jean-sur-Richelieu, Quebec
J2X 5K8
Canada
Tel: (450) 358-4600
Toll-free: 1-800-831-AUBE
Fax: (450) 358-4650
Email: aube.service@honeywell.com
10, rue Ampère
95500 Gonesse
France
Tel: 33 (0) 1 34 07 99 00
Fax: 33 (0) 1 34 07 99 19
Email: advaube@comintes.com
