How the Air Purifier Works
3
A Word About the AM-90
Setting the Fan Speed:
A. If the unit is in the stand-by mode and the SPEED button (2) is pressed,
the unit will start operating at the high fan speed.
B. Pressing the SPEED button (2) repeatedly will cycle through this sequence:
high fan speed – medium fan speed – low fan speed – stand-by mode.
C. The fan speed is shown on the LCD screen with bar graphs on each side and by the fan symbol
,
turning at different rates.
Ionizer
A. Press the IONIZER button (3) when the unit is operating and the IONIZER will turn on and off.
B. The IONIZER operation is shown on the LCD screen with a tree symbol
with upward motion.
Timer Operation: 8 h
A. Press the TIMER button (4) repeatedly when the unit is operating and the timer digit at bottom of
the LCD screen will count up from 1 to 8 hours, turn off the timer function and then start again
counting up from 1 to 8 hours.
B. The unit will operate for the number of hours selected using the TIMER button (4).
As each hour passes the timer digit display will go down one hour.
C. At the end of the timed period the unit will turn off.
This manual has been prepared to acquaint you with the proper installation, operation and maintenance
of your AM-90 Air Purifier. We urge you to read this publication carefully and to follow the
recommendations to help assure the most enjoyable and trouble free operation of your Amcor unit.
When it comes to service, remember that Amcor knows its product best.
Please do not attempt to open, repair and/or clean any of the internal parts of the AM-90 Air Purifier
yourself. This could result in loss of the warranty.
We would like to take this opportunity to thank you for choosing an Amcor product, and to assure
you of our continuing interest in your comfort, pleasure and health.
Safety
• The AM-90 Air Purifier is safe. It is listed by ETL and it has been designed with special attention
to safety. However, as with other electrical appliances, use it with care.
• Do not clean the AM-90 Air Purifier by spraying it or immersing it in water.
• Do not insert any object into the openings of the AM-90 Air Purifier.
• Disconnect the product from the electrical outlet before cleaning the unit or any of its components.
• Do not connect the AM-90 Air Purifier to an electric outlet using an extension cord.
If there is no accessible outlet, a licensed electrician should install one.
• WHEN NOT IN USE STORE OUT OF REACH OF CHILDREN!
Warning
• Any service, other than regular cleaning or filter replacement should be performed by an authorized
service representative. Failure to do so could result in loss of warranty.
• To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider
than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact qualified personnel to install the
proper outlet.
Do not alter the plug in any way.
• If the supply cord becomes damaged, it must be replaced by the manufacturer or its service agent
or similarly qualified person in order to avoid a hazard.
