Installing Exhaust Hose to Window Slide Bar
AfterassemblingInnovativeAutoDrainNanoMistTechnology
™
perinstructionsonpage5,
make sure hose is firmly attached to oval connecter that fits into window slide bar.
Snap hose connecter into window slide bar opening. See Illustration 1.
Extendwindowslidebartotyourwindowopening,eitherverticalorhorizontal,
dependingonhowthewindowopens.SeeIllustrations2a-2b.
Important
The flexible exhaust hose can be extended from 12" to 60" for mounting.
This length has been designed especially according to the specifications of the
air conditioner.
Do not use an extension or exchange for a different hose as that may lead to
malfunctioning.
Theexhaustairmustowfreely,anyblockagecanleadtooverheatingoftheairconditioner.
Takecaretopreventanykinkorbendintheexhausthose.
Thisunitcaneasilybemovedfromoneroomtoanother.Indoingsokeepthisinmind:
• Theairconditionermuststanduprightonanevensurface.
• Donotpositionnearbath,sink,orotherpermanentwetordamparea.
• Keepunitatleast18"fromwall,curtains,draperies,toinsureadequateaircirculation.
1
2
b
2
a
Positioning
6
