Amcor 9000E Air Conditioner User Manual



66
Setting the temperature
If you want to change the set temperature press
or to set the temperature. The 2 digit
display will indicate the set temperature.
Note: Reaching the set temperature depends on the room and outdoor climatic conditions.
Mode switch
Press the
button successively until the icon representing the desired mode is appearing
(=> Cool => Fan => Heat => etc). On the LCD-display you will see:
Cooling
Fan only Heat
Each time the unit starts, it starts operating in cool mode with a set temperature of 22°C. The
fan speed will be selected automatically. Heat mode is only available on EH models.
Fan speed
If you prefer a constant fan speed instead of the auto fan speed, press the
button
successively; the fan icon
on the LCD-display will rotate accordingly.
• Fast - for the turbo speed
• Normal - for the medium speed
• Slow - for the slow speed
• Alternating - for the auto fan speed (in the cooling mode only!)
Heat
EH models feature a 1650 W electric heater that can heat a room on cooler days. With
the mode switch select
, set the desired temperature and the unit will heat until this
temperature is reached. Fan speed is selected automatically. Do not place the unit near
anything that could catch fire or be scorched. Do not obstruct the air outlet. The heat
function will operate with or without the hose attached.
Timer
For all of the following TIMER programming, proceed firstly with these standard steps:
• Press the
button briefly; the 2 left digits of the 4 digits on the LCD display are flashing.
• Press or to adjust the hour.
• Press the
button briefly again, the 2 right digits of the 4 digits are flashing.
• Press or to adjust the minutes of the clock in intervals of 5 minutes. The timer is set.
After 10 seconds the time display returns.
Programming the timer for ON - when the unit is OFF.
• Perform the standard steps as described above.
The circular time scale will be on between the ON programmed times
until 24:00. The flashing bar on the time scale indicates the real time and
moves a segment ahead every 30 minutes until it reaches the ON timer
time, then the black segments in the circular time scale will disappear.
Programming the timer for OFF - when the unit is RUNNING.
• Perform the standard steps as described above.
The circular time scale will be on between the present time to the OFF programmed time.
The flashing bar on the time scale indicates the real time and moves a segment ahead every
30 minutes until it reaches the OFF timer time, then the black segments in the circular time
scale will disappear.
Timer example
