271457-YTG-B-0908
Johnson Controls Unitary Products 13
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the
total electric power input during the same period.
— = Not Applicable.
HEATING PERFORMANCE - With Air Handler
UNIT
MODEL*
AIR
HANDLER
COIL
1
MODEL
ARI HEATING
2
47°F17°F HSPF
MBH COP KW MBH COP KW
STD
1 PH 13 SEER HP WITH MA
YZB01811 MA08B
FC/M
C18B
18.0 3.28 1.61 11.6 2.32 1.46 8.00
YZB02411
MA08B FC/MC24B 24.0 3.44 2.04 14.2 2.38 1.75 8.00
MA08B FC/MC30B 24.0 3.44 2.04 14.2 2.38 1.75 8.00
YZB03011 MA12B FC/MC36B 30.0 3.44 2.56 18.3 2.28 2.35 8.00
YZB03611 MA12B FC/MC36B 36.0 3.36 3.14 24.4 2.32 3.08 8.00
YZB04211
MA16C FC/MC48C 42.0 3.66 3.36 28.4 2.54 3.28 8.00
MA14D FC/MC48D 42.0 3.66 3.36 28.4 2.54 3.28 8.00
YZB04811
MA16C FC60C 48.0 3.50 4.10 33.2 2.30 4.23 8.00
MA20D FC/MC60D 48.0 3.50 4.10 33.2 2.30 4.23 8.00
MA20D MC61D 48.0 3.50 4.10 33.2 2.30 4.23 8.00
YZB06012 MA20D FC/MC62D 57.0 3.54 4.77 37.0 2.44 4.49 8.55
1 PH 13 SEER HP WITH MV - VARIABLE SPEED
YZB01811 MV12B FC/MC18B 18.0 3.46 1.52 11.1 2.46 1.32 8.35
YZB02411
MV12B FC/MC24B 23.4 3.44 1.99 14.2 2.38 1.75 8.30
MV12B FC/MC30B 23.4 3.44 1.99 14.2 2.38 1.75 8.30
YZB03011
MV12B FC/MC36B 29.4 3.44 2.50 18.3 2.28 2.35 8.20
MV16C FC/MC36C 29.4 3.44 2.50 18.3 2.28 2.35 8.20
YZB03611 MV12B FC/MC36B 36.0 3.36 3.14 24.4 2.32 3.08 8.30
YZB04211
MV16C FC/MC48C 42.0 3.66 3.36 28.4 2.54 3.28 8.60
MV20D FC/MC48D 42.0 3.66 3.36 28.4 2.54 3.28 8.60
YZB04811
MV16C FC/MC60C 48.0 3.50 4.02 33.2 2.30 4.23 8.10
MV20D FC/MC60D 48.0 3.50 4.02 33.2 2.30 4.23 8.10
MV20D MC61D 48.0 3.50 4.02 33.2 2.30 4.23 8.10
YZB06012 MV20D FC/MC62D 56.0 3.56 4.65 37.0 2.48 4.37 8.65
1 PH 13 SEER HP WITH AV / SV / F*FV - VARIABLE SPEED
YZB01811 AV24 – 18.0 3.42 1.54 11.2 2.24 1.46 8.25
YZB02411 AV24 – 23.2 3.68 1.85 13.5 2.28 1.73 8.25
YZB03011 AV36 – 29.2 3.66 2.34 17.6 2.20 2.34 8.15
YZB03611
AV36 – 36.03.363.1424.42.323.088.30
AV/SV48 – 36.03.503.0123.62.263.068.30
YZB04211 AV/SV48 – 42.0 3.82 3.22 27.8 2.48 3.28 8.20
YZB04811
AV/SV48 – 48.03.603.9132.62.264.238.10
F*FV060 – 48.03.504.2333.22.304.238.10
1 PH 13 SEER HP WITH AHP / SHP / F*FP
YZB01811
AHP18 – 18.0 3.28 1.61 11.6 2.32 1.46 8.00
F*FP024 – 18.0 3.30 1.77 11.5 2.32 1.45 8.05
YZB02411
AHP24 – 24.03.442.0414.22.381.758.00
F*FP030 – 23.83.442.0314.22.381.758.00
YZB03011
AHP30 – 30.03.442.5618.32.282.358.00
AHP36 – 30.03.442.5618.32.282.358.00
F*FP036 – 29.63.442.5218.32.282.358.00
YZB03611
AHP36 – 36.03.363.1424.42.323.088.00
AHP42 – 36.03.363.1424.42.323.088.00
F*FP036 – 36.03.363.2324.42.323.088.00
F*FP042 – 36.03.363.2324.42.323.088.00
YZB04211 AHP/SHP48 – 42.0 3.66 3.36 28.4 2.54 3.28 8.00
YZB04811
AHP/SHP48 – 48.03.504.1033.22.304.238.00
AHP/SHP60 – 48.03.504.1033.22.304.238.00
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no
supplemental electric heat operation.
