TECHNICAL SPECIFICATIONS
Technical Specifications : Duct Type YUHC “R-410A” -50Hz
Models
Indoor
Unit
YUKC
18 24 30 36 48 60
Outdoor
Unit
YUJC
18 24 30 36 48 60
Power Supply
V/Ph/Hz 220-240/1/50 380/3/50
Ph 1 1 3 3 3 3
Power Consumption W 1,900/1,900 2,560/2,500 3,250/3,250 3,700/3,350 4,700/4,900 6,000/6,000
Running Current A 8.8/8.8 12.2/11 5.5/5.5 6.5/5.8 8.2/8.6 9.8/9.8
Refrigerant Type
R-410A
Refrigerant Charge gr 2,050 2,600 3,100 3,100 4,000 4,200
Noise level
Indoor
dB(A)
38 38 44 44 46 47
Outdoor 48 55 57 57 58 58
Indoor Unit
Power Supply
V/Ph/Hz 220-240/1/50
Ph 1 1 1 1 1 1
Fan
Air flow m
3
/h 1,160 1,460 2,070 2,070 2,400 2,800
Input Power W 117 170 118 118 118 227
Running Current A 0.53 0.77 0.54 0.54 0.54 1.03
Dimension
Height mm 300 300 300 300 300 320
Width
mm 1,000 1,000 1,350 1,350 1,350 1,350
Depth mm 800 800 800 800 800 800
Weight
kg 36 38 48 48 50 70
System Operation Control Wireless Control with LCD Display
Outdoor Unit
Power Supply
V/Ph/Hz 220-240/1/50 380/3/50
Ph 1 1 3 3 3 3
Compressor
Qty 1 1 1 1 1 1
Compressor Type
Rotary Scroll
Dimension
Height mm 695 860 960 960 1,245 1,245
Width
mm 845 895 990 990 940 940
Depth mm 335 330 360 360 360 360
Weight
kg 55 79 101 101 110 110
Piping
Type Flare + Nuts
Pipe Size
Suction inch 1/2 5/8 3/4 3/4 3/4 3/4
Liquid inch 1/4 3/8 1/2 1/2 1/2 1/2
