YORK INTERNATIONAL
23
FORM 150.63-EG1
NOTES:
1. SST = Saturated Suction Temperature
2. kW = Compressors Input Power
3. EER = Condensing Unit EER (includes power from compressors, fans and the control panel)
YCUL0060EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
105°F 110°F 115°F 120°F 125°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
44.4 63.4 7.7 42.9 67.0 7.1 41.4 70.7 6.5 29.5 51.2 6.2 28.4 54.0 5.7
37.0
46.0 63.9 7.9 44.6 67.5 7.3 43.0 71.3 6.7 30.7 51.5 6.5 29.5 54.4 5.9
39.0
47.7 64.4 8.2 46.2 68.0 7.5 33.1 49.0 7.3 31.9 51.8 6.7 21.8 35.1 6.4
41.0
49.5 64.9 8.4 47.9 68.6 7.7 34.3 49.3 7.5 33.1 52.1 6.9 22.7 35.2 6.7
43.0
51.2 65.4 8.7 49.6 69.1 8.0 35.6 49.6 7.7 34.4 52.4 7.1 23.5 35.4 6.9
45.0
53.0 66.0 8.9 51.4 69.7 8.2 36.9 49.9 8.0 35.6 52.7 7.3 24.4 35.6 7.1
47.0
54.9 66.5 9.1 53.1 70.2 8.4 38.2 50.2 8.2 36.9 53.0 7.6 25.3 35.7 7.4
49.0
56.7 67.1 9.4 55.0 70.8 8.6 39.6 50.5 8.5 38.2 53.4 7.8 26.2 35.9 7.6
51.0
58.6 67.7 9.6 42.3 48.1 9.5 41.0 50.8 8.7 39.6 53.7 8.0 27.2 36.0 7.8
53.0
60.6 68.2 9.8 43.8 48.4 9.7 42.4 51.1 9.0 41.0 54.0 8.2 28.2 36.2 8.1
55.0
62.6 68.8 10.1 45.2 48.7 10.0 43.8 51.5 9.2 30.2 34.4 9.1 29.2 36.3 8.3
YCUL0066EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
105°F 110°F 115°F 120°F 125°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
49.2 66.6 8.2 47.7 70.4 7.5 46.1 74.3 6.9 44.6 78.3 6.4 22.4 36.8 6.3
37.0
51.0 67.1 8.4 49.5 70.9 7.8 47.9 74.8 7.1 46.3 78.9 6.6 23.2 37.0 6.5
39.0
52.9 67.6 8.7 51.3 71.4 8.0 49.6 75.4 7.4 48.0 79.5 6.8 24.1 37.2 6.8
41.0
54.8 68.2 8.9 53.1 72.0 8.2 51.5 76.0 7.6 25.9 35.3 7.6 25.0 37.4 7.0
43.0
56.8 68.7 9.2 55.1 72.6 8.5 53.3 76.6 7.8 26.9 35.5 7.9 26.0 37.5 7.2
45.0
58.8 69.3 9.4 57.0 73.2 8.7 55.2 77.2 8.0 27.9 35.7 8.1 27.0 37.7 7.5
47.0
60.8 69.9 9.7 59.0 73.8 8.9 57.1 77.9 8.2 28.9 35.8 8.4 28.0 37.9 7.7
49.0
62.9 70.5 9.9 61.0 74.4 9.2 59.1 78.5 8.4 30.0 36.0 8.6 29.0 38.1 8.0
51.0
65.0 71.1 10.2 63.1 75.0 9.4 61.1 79.2 8.7 31.0 36.2 8.9 30.0 38.3 8.2
53.0
67.2 71.7 10.4 65.2 75.7 9.6 63.2 79.8 8.9 32.1 36.4 9.2 31.1 38.5 8.5
55.0
69.4 72.4 10.7 67.3 76.4 9.9 34.3 34.6 10.2 33.3 36.6 9.5 32.2 38.7 8.7
YCUL0076EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
105°F 110°F 115°F 120°F 125°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
54.1 77.3 7.7 52.3 81.7 7.1 50.3 86.3 6.5 40.5 71.0 6.3 39.0 75.0 5.7
37.0
56.2 77.9 8.0 54.2 82.3 7.3 52.3 86.9 6.7 42.1 71.4 6.5 40.5 75.4 5.9
39.0
58.2 78.5 8.2 56.3 82.9 7.5 54.3 87.6 6.9 43.8 71.9 6.7 42.1 75.9 6.1
41.0
60.3 79.1 8.4 58.3 83.5 7.8 56.3 88.2 7.1 45.4 72.3 6.9 43.7 76.4 6.3
43.0
62.5 79.7 8.7 60.4 84.2 8.0 58.3 88.9 7.3 47.1 72.7 7.1 37.6 60.2 6.7
45.0
64.7 80.3 8.9 62.6 84.8 8.2 60.4 89.6 7.5 48.8 73.2 7.3 39.0 60.5 7.0
47.0
67.0 80.9 9.2 64.8 85.4 8.4 52.4 69.7 8.2 50.6 73.7 7.5 40.5 60.8 7.2
49.0
69.3 81.5 9.4 67.0 86.1 8.7 54.2 70.2 8.5 52.4 74.1 7.8 41.9 61.1 7.4
51.0
71.6 82.1 9.7 69.3 86.8 8.9 56.1 70.6 8.7 54.2 74.6 8.0 43.4 61.4 7.6
53.0
74.0 82.8 9.9 71.6 87.4 9.1 58.0 71.0 8.9 56.1 75.0 8.2 45.0 61.7 7.9
55.0
76.4 83.5 10.2 74.0 88.1 9.3 60.0 71.5 9.2 58.0 75.5 8.5 46.6 62.0 8.1
YCUL0080EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
105°F 110°F 115°F 120°F 125°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
60.6 84.9 7.9 58.5 89.8 7.3 56.3 94.9 6.6 54.0 100.2 6.1 35.9 65.2 6.0
37.0
62.9 85.5 8.2 60.7 90.5 7.5 58.5 95.5 6.9 56.2 100.9 6.3 37.4 65.5 6.2
39.0
65.2 86.2 8.4 63.0 91.0 7.7 60.7 96.2 7.1 58.4 101.6 6.5 38.9 65.8 6.4
41.0
67.6 86.7 8.7 65.3 91.7 8.0 63.0 96.9 7.3 42.0 62.6 7.3 40.4 66.2 6.6
43.0
70.0 87.3 8.9 67.7 92.3 8.2 65.3 97.6 7.5 43.6 62.8 7.5 42.0 66.4 6.9
45.0
72.5 88.0 9.2 70.1 93.0 8.4 67.7 98.2 7.7 45.2 63.1 7.8 43.6 66.8 7.1
47.0
75.0 88.6 9.4 72.6 93.6 8.7 70.1 98.9 8.0 46.9 63.4 8.0 45.2 67.1 7.3
49.0
77.6 89.2 9.7 75.1 94.3 8.9 72.6 99.6 8.2 48.6 63.7 8.3 46.8 67.4 7.6
51.0
80.3 89.8 10.0 77.7 94.9 9.2 75.1 100.3 8.4 50.3 64.0 8.5 48.5 67.7 7.8
53.0
82.9 90.5 10.2 80.3 95.6 9.4 77.6 101.0 8.6 52.1 64.3 8.8 50.3 68.0 8.1
55.0
85.7 91.2 10.5 83.0 96.3 9.7 80.2 101.7 8.9 53.9 64.6 9.1 52.0 68.3 8.3
