528194-YTG-F-1210
Johnson Controls Unitary Products 23
ZF120 (10 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
2500
77 165.2 7.4 67.4 56.3 45.3 - - - 153.8 8.3 62.7 51.8 40.9 - - -
72 149.2 7.5 84.0 72.9 61.8 50.8 - - 138.9 8.3 79.2 68.3 57.4 46.5 - -
67 133.2 7.5 100.5 89.4 78.4 67.3 56.3 - 124.0 8.2 95.7 84.8 73.9 63.0 52.1 -
62 121.8 7.5 121.8 105.9 93.0 82.0 70.9 59.8 112.8 8.2 112.8 103.2 88.0 77.1 66.2 55.3
3000
77 170.9 7.4 76.4 63.0 49.7 - - - 159.0 8.3 71.2 58.2 45.2 - - -
72 154.3 7.4 94.5 81.2 67.8 54.5 - - 143.5 8.3 89.4 76.4 63.4 50.4 - -
67 137.7 7.4 112.6 99.3 86.0 72.7 59.3 - 128.1 8.2 107.6 94.6 81.6 68.5 55.5 -
62 125.9 7.5 125.9 115.4 102.0 88.7 75.4 62.1 116.5 8.2 116.5 110.1 97.1 84.1 71.1 58.0
57 120.2 7.4 120.2 120.2 109.7 96.3 83.0 69.7 112.6 8.2 112.6 112.6 101.9 88.9 75.8 62.8
3500
77 176.6 7.4 85.3 69.7 54.1 - - - 164.1 8.3 79.7 64.6 49.4 - - -
72 159.4 7.4 105.0 89.5 73.9 58.3 - - 148.2 8.3 99.6 84.5 69.3 54.2 - -
67 142.3 7.4 124.8 109.2 93.6 78.0 62.4 - 132.3 8.2 119.5 104.3 89.2 74.1 58.9 -
62 130.1 7.5 130.1 124.8 111.1 95.5 79.9 64.3 120.3 8.2 120.3 117.1 106.2 91.1 75.9 60.8
57 124.2 7.4 124.2 124.2 119.4 103.8 88.2 72.6 116.3 8.2 116.3 116.3 111.4 96.3 81.1 66.0
4000
77 182.2 7.3 94.3 76.4 58.6 - - - 169.2 8.3 88.2 70.9 53.7 - - -
72 164.5 7.4 115.6 97.7 79.9 62.0 - - 152.8 8.3 109.8 92.5 75.3 58.0 - -
67 146.8 7.4 136.9 119.1 101.2 83.3 65.5 - 136.4 8.2 131.4 114.1 96.9 79.6 62.3 -
62 134.3 7.4 134.3 134.3 120.1 102.2 84.4 66.5 124.1 8.2 124.1 124.1 115.3 98.0 80.8 63.5
57 128.2 7.4 128.2 128.2 129.1 111.3 93.4 75.5 119.9 8.2 119.9 119.9 121.0 103.7 86.4 69.2
4500
72 168.0 7.4 124.0 104.8 85.6 66.4 - - 155.6 8.3 117.7 99.1 80.5 61.8 - -
67 149.9 7.4 144.9 127.7 108.5 89.2 70.0 - 138.9 8.3 136.4 122.2 103.5 84.9 66.3 -
62 137.1 7.4 137.1 137.1 130.0 110.8 91.5 72.3 126.3 8.2 126.3 126.3 122.0 103.3 84.7 66.0
57 130.9 7.4 130.9 130.9 131.3 112.1 92.9 73.7 122.1 8.2 122.1 122.1 122.6 104.0 85.4 66.7
5000
72 171.4 7.4 132.5 111.9 91.3 70.7 - - 158.4 8.3 125.7 105.7 85.7 65.6 - -
67 153.0 7.4 153.0 136.3 115.7 95.1 74.5 - 141.4 8.3 141.4 130.2 110.2 90.2 70.2 -
62 139.9 7.5 139.9 139.9 139.9 119.3 98.7 78.1 128.6 8.2 128.6 128.6 128.6 108.6 88.6 68.6
57 133.5 7.4 133.5 133.5 133.5 113.0 92.4 71.8 124.3 8.2 124.3 124.3 124.3 104.3 84.3 64.2
95°F 105°F
2500
77 142.4 9.2 58.1 47.3 36.6 - - - 129.8 10.2 56.2 45.6 34.9 - - -
72 128.6 9.1 74.5 63.7 53.0 42.3 - - 117.4 9.9 74.6 63.8 53.1 42.4 - -
67 114.8 9.0 90.9 80.2 69.4 58.7 48.0 - 104.9 9.7 93.0 82.1 71.4 60.6 49.9 -
62 103.8 8.8 103.8 100.4 83.0 72.3 61.5 50.8 94.6 9.5 94.6 92.9 82.3 71.6 60.8 50.1
3000
77 147.0 9.2 66.1 53.4 40.7 - - - 133.5 10.2 65.1 50.3 37.6 - - -
72 132.8 9.1 84.3 71.6 58.9 46.2 - - 120.8 10.0 82.5 69.8 57.1 44.5 - -
67 118.6 9.0 102.5 89.8 77.1 64.4 51.7 - 108.0 9.8 100.0 89.4 76.7 64.0 51.3 -
62 107.1 8.9 107.1 104.9 92.2 79.5 66.7 54.0 97.3 9.5 97.3 96.2 89.9 77.2 64.5 51.8
57 105.0 8.9 105.0 105.0 94.1 81.4 68.7 56.0 97.9 9.6 97.9 97.9 91.0 78.3 65.6 52.9
3500
77 151.6 9.3 74.1 59.4 44.7 - - - 137.3 10.3 74.0 54.9 40.3 - - -
72 137.0 9.2 94.2 79.5 64.8 50.1 - - 124.1 10.1 90.5 75.8 61.2 46.5 - -
67 122.3 9.1 114.2 99.5 84.8 70.1 55.4 - 111.0 9.8 106.9 96.7 82.0 67.4 52.7 -
62 110.5 8.9 110.5 109.4 101.4 86.7 72.0 57.3 100.1 9.6 100.1 99.5 97.4 82.8 68.1 53.5
57 108.3 8.9 108.3 108.3 103.5 88.8 74.1 59.4 100.6 9.7 100.6 100.6 97.4 82.7 68.1 53.4
4000
77 156.2 9.3 82.1 65.4 48.8 - - - 141.0 10.4 82.9 59.6 43.0 - - -
72 141.1 9.2 104.0 87.3 70.6 54.0 - - 127.5 10.1 98.4 81.8 65.2 48.6 - -
67 126.0 9.1 125.9 109.2 92.5 75.8 59.1 - 114.0 9.9 113.9 104.0 87.4 70.8 54.2 -
62 113.9 8.9 113.9 113.9 110.5 93.9 77.2 60.5 102.8 9.7 102.8 102.8 105.0 88.4 71.8 55.2
57 111.6 8.9 111.6 111.6 112.9 96.2 79.5 62.8 103.4 9.7 103.4 103.4 103.8 87.2 70.6 54.0
4500
72 143.3 9.2 111.4 93.4 75.3 57.2 - - 129.6 10.2 105.3 87.4 69.5 51.5 - -
67 127.9 9.1 127.9 116.7 98.6 80.6 62.5 - 115.9 9.9 115.8 109.5 93.1 75.2 57.2 -
62 115.6 9.0 115.6 115.6 114.0 95.9 77.8 59.7 104.5 9.7 104.5 104.5 105.6 87.6 69.7 51.8
57 113.3 9.0 113.3 113.3 114.0 95.9 77.8 59.7 105.1 9.7 105.1 105.1 105.3 87.4 69.4 51.5
5000
72 145.5 9.2 118.9 99.4 80.0 60.5 - - 131.7 10.2 112.2 93.0 73.7 54.5 - -
67 129.9 9.1 129.9 124.2 104.8 85.3 65.8 - 117.7 9.9 117.7 114.9 98.8 79.5 60.3 -
62 117.4 9.0 117.4 117.4 117.4 97.9 78.4 59.0 106.2 9.7 106.2 106.2 106.2 86.9 67.6 48.4
57 115.1 9.0 115.1 115.1 115.1 95.6 76.1 56.7 106.8 9.8 106.8 106.8 106.8 87.5 68.3 49.0
