288429-YIM-A-0307
Unitary Products Group 13
048
(4.0)
DEX
Cool
Low
Y1 COOL-A 1050 184 216 248 280 313 346 380 414 449
Y1 COOL-B 920 139 166 195 224 255 286 319 352 386
Y1 COOL-C 980 159 188 218 249 281 313 346 379 414
Y1 COOL-D 1120 211 245 279 313 348 382 417 452 486
High
Y1+Y2 COOL-A 1600 448 500 551 600 647 693 736 779 819
Y1+Y2 COOL-B 1400 338 383 426 468 509 549 589 627 664
Y1+Y2 COOL-C 1500 391 439 486 532 576 618 660 700 739
Y1+Y2 COOL-D 1700 508 565 620 672 723 772 818 863 905
Heat
W1 HEAT-A 1600 448 500 551 600 647 - - - -
W1 HEAT-B 1440 359 405 449 493 535 - - - -
W1 HEAT-C 1760 546 606 663 718 771 - - - -
W1 HEAT-D 1600 448 500 551 600 647 - - - -
060
(5.0)
DEY
Cool
Low
Y1 COOL-A 1170 235 283 328 368 404 435 463 485 505
Y1 COOL-B 1110 205 258 304 345 381 410 434 451 465
Y1 COOL-C 1210 255 301 344 384 420 454 483 509 533
Y1 COOL-D 1270 286 329 371 410 448 483 516 547 576
High
Y1+Y2 COOL-A 1750 559 608 658 710 762 815 870 925 981
Y1+Y2 COOL-B 1650 498 542 588 634 683 732 783 835 888
Y1+Y2 COOL-C 1800 590 643 696 750 805 860 916 973 1030
Y1+Y2 COOL-D 1900 654 715 775 836 895 955 1013 1072 -
Heat
W1 HEAT-A 1900 654 715 775 836 895 - - - -
W1 HEAT-B 1975 703 772 839 904 968 - - - -
W1 HEAT-C 2150 823 913 999 1079 1154 - - - -
W1 HEAT-D 2070 767 847 923 997 1066 - - - -
Table 8: Bottom Duct Application
Size
(Tons)
Model Mode
Thermostat
Input
Speed
Tap
CFM
External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
024
(2.0)
DEX
Cool
Low
Y1 COOL-A 600 57 74 91 108 126 143 161 179 197
Y1 COOL-B 450 39 54 69 84 100 117 134 152 171
Y1 COOL-C 525 47 63 79 95 112 129 146 164 182
Y1 COOL-D 675 71 88 106 124 142 161 179 198 216
High
Y1+Y2 COOL-A 800 99 117 137 156 176 196 217 237 258
Y1+Y2 COOL-B 600 57 74 91 108 126 143 161 179 197
Y1+Y2 COOL-C 700 76 94 112 130 148 167 186 205 224
Y1+Y2 COOL-D 900 126 146 166 187 208 231 253 277 300
Heat
W1 HEAT-A80099117137156-----
W1 HEAT-B7208098116135-----
W1 HEAT-C880120140160180-----
W1 HEAT-D80099117137156-----
030
(2.5)
DEX
Cool
Low
Y1 COOL-A 670 61 78 95 113 130 148 166 184 201
Y1 COOL-B 620 54 70 87 104 121 138 156 173 191
Y1 COOL-C 720 70 88 106 124 142 160 178 197 215
Y1 COOL-D 770 81 99 118 136 155 174 193 213 232
High
Y1+Y2 COOL-A 1000 159 179 200 222 246 270 296 323 350
Y1+Y2 COOL-B 925 129 148 169 190 211 233 256 280 304
Y1+Y2 COOL-C 1075 194 214 236 260 285 312 341 371 403
Y1+Y2 COOL-D 1150 233 254 277 302 330 360 392 427 463
Heat
W1 HEAT-A1000159179200222-----
W1 HEAT-B900120139159180-----
W1 HEAT-C1100206227249274-----
W1 HEAT-D1000159179200222-----
036
(3.0)
DEX
Cool
Low
Y1 COOL-A 900 120 139 159 180 201 222 244 267 291
Y1 COOL-B 750 76 94 113 131 150 168 187 206 225
Y1 COOL-C 830 97 116 135 155 174 194 215 236 256
Y1 COOL-D 980 150 170 191 213 236 260 285 311 337
High
Y1+Y2 COOL-A 1200 261 283 306 333 362 394 429 467 507
Y1+Y2 COOL-B 1000 159 179 200 222 246 270 296 323 350
Y1+Y2 COOL-C 1100 206 227 249 274 300 328 357 389 422
Y1+Y2 COOL-D 1300 325 346 372 401 434 471 511 556 604
Heat
W1 HEAT-A1200261283306333-----
W1 HEAT-B1080196217239263-----
W1 HEAT-C1275308330355383-----
W1 HEAT-D1200261283306333-----
Table 7: Side Duct Application (Continued)
Size
(Tons)
Model Mode
Thermostat
Input
Speed
Tap
CFM
External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
