Multipliers for determining the performance with other indoor sections.
COOLING PERFORMANCE DATA -
LOW CFM 1-CYLINDER OPERATION
AIR CONDITIONER MODEL NO. H4TS048S06
INDOOR COIL MODEL NO. G2FD048S24+N1VSD20
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1450 1600 1750
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75
T.C. 29.2 26.7 24.3 21.9 29.5 27.1 24.6 22.4 29.7 27.4 24.9 22.8
S.C. 19.4 19.4 19.6 19.5 20.5 20.6 20.7 20.7 21.5 21.6 21.7 21.7
K.W 1.43 1.43 1.42 1.41 1.46 1.46 1.45 1.44 1.49 1.49 1.48 1.48
85
T.C. 27.7 25.3 23.0 20.8 28.0 25.7 23.3 21.2 28.4 25.9 23.5 21.8
S.C. 18.9 18.8 19.0 19.1 20.0 20.0 20.1 20.0 21.1 21.0 21.0 20.7
K.W 1.57 1.56 1.54 1.53 1.60 1.59 1.57 1.56 1.64 1.62 1.61 1.59
95
T.C. 26.1 23.9 21.7 19.7 26.3 24.2 22.0 20.2 26.7 24.4 22.3 20.6
S.C. 18.3 18.3 18.5 18.4 19.4 19.4 19.5 19.2 20.6 20.4 20.6 19.6
K.W 1.69 1.68 1.66 1.63 1.72 1.71 1.69 1.67 1.76 1.74 1.73 1.71
105
T.C. 24.5 22.5 20.3 18.6 24.9 22.7 20.7 19.1 25.1 22.8 21.0 19.4
S.C. 17.8 17.8 17.8 17.7 18.9 18.8 19.0 18.0 19.9 19.8 20.0 18.4
K.W 1.81 1.78 1.76 1.73 1.84 1.82 1.80 1.77 1.88 1.85 1.83 1.81
115
T.C. 22.9 20.9 18.9 17.4 23.1 21.2 19.3 17.8 23.3 21.3 19.7 18.1
S.C. 17.3 17.2 17.2 16.6 18.3 18.1 18.2 17.0 19.3 19.1 18.7 17.3
K.W 1.92 1.88 1.85 1.83 1.95 1.92 1.89 1.86 1.99 1.95 1.93 1.90
125
T.C. 21.4 19.4 17.4 16.3 21.4 19.7 17.8 16.6 21.6 19.7 18.5 16.8
S.C. 16.8 16.6 16.5 15.5 17.8 17.5 17.5 15.9 18.7 18.4 17.5 16.1
K.W 2.03 1.98 1.94 1.92 2.06 2.02 1.98 1.96 2.09 2.05 2.03 1.99
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
N1VSC16 G2FD048S21 1.00 1.03 1.01
N1VSD20 G2FD060S24 1.02 1.12 1.08
F2FV060 1.02 1.12 1.08
F2RP/F2FP048 0.99 1.03 0.96
F2RP/F2FP060 1.03 1.10 1.03
G1HD060 1.01 1.03 1.17
G1FA048S21 1.01 1.03 1.17
G1FA060S21,24 0.99 1.03 1.15
GFD048S21,24 0.99 1.03 1.15
G2FD060S24 1.01 1.08 1.17
G1UA048S21 1.01 1.03 1.17
G1UA060S21,24 0.99 1.03 1.15
Variable Speed
Furnace
Coil
T.C. S.C. KW
P1DUC20V096 G1FA048S21 0.99 0.98 1.04
P1DUC20V096 G1UA048S21 0.99 0.98 1.04
P1XUC16V075 G1FA048S21 0.99 0.98 1.04
P1XUC16V075 G1UA048S21 0.99 0.98 1.04
P1XUC20V095 G1FA048S21 0.99 0.98 1.03
P1XUC20V095 G1UA048S21 0.99 0.98 1.03
P1DUC20V096 G1FA060S21 1.03 1.03 1.10
P1DUC20V096 G1UA060S21 1.03 1.03 1.10
P1XUC16V075 G1FA060S21 1.03 1.03 1.11
P1XUC16V075 G1UA060S21 1.03 1.03 1.11
P1XUC20V095 G1FA060S21 1.03 1.03 1.10
P1XUC20V095 G1UA060S21 1.03 1.03 1.10
P1DUC20V096 G2FD048S21 0.99 0.98 1.01
P1XUC16V075 G2FD048S21 0.99 0.98 1.03
P1XUC20V095 G2FD048S21 0.99 0.98 1.01
P1XUD20V112 G1FA060S24 1.04 1.04 1.07
P1XUD20V112 G1UA060S24 1.04 1.04 1.07
P1XUD20V112 G2FD048S24 0.99 0.98 1.01
P1XUD20V112 G2FD060S24 1.04 1.04 1.07
