Panel Controls and Terminals
PSR-S550 Owner’s Manual 15
@3 CATEGORY [ ] and [ ] buttons .....page 41
@4 [EXECUTE] button........................... page 68
@5 [MDB] button ...................................page 26
@6 [FILE MENU] button ........................page 83
@7 [FUNCTION] button .........................page 80
@8 ONE TOUCH SETTING [1]–[4]
buttons............................................. page 58
@9 VOICE ...............................................page 17
#0 VOICE CONTROL
[LEFT] button................................ page 19
[DUAL] button ............................... page 18
[HARMONY] button ......................page 44
[TOUCH] button ............................page 51
[SUSTAIN] button .........................page 47
[DSP] button..................................page 47
#1 UPPER OCTAVE [+] and [-] buttons
.......................................................... page 54
#2 [PITCH BEND] wheel....................... page 48
#3 Drum Kit........................................... page 21
#4 SUSTAIN jack................................... page 10
#5 USB TO HOST and TO DEVICE
terminals.......................................... page 90
#6 CONTRAST knob ............................ page 12
#7 PHONES/OUTPUT jack................... page 10
#8 DC IN 16V jack................................. page 10
