112
Menu Organization and Operation
Chapter 5 Menu Displays and Detailed Settings
10 OUTPUT SDI OUTPUT SEL HD / SD HD 07 Selects HD or SD as the SDI
output of this unit.
Notes
• When you have changed the
setting of this item, turn the
power of the unit off and then on
again.
• SD cannot be selected when the
23.98PsF signal output mode is
selected and the unit is in HD
output mode.
A
HD→SD ASPECT 16:9 / 4:3 16:9 Selects the aspect ratio for down-
converted output to an SD monitor
of playback of material recorded in
HD format.
You can select 16:9 (squeeze) or
4:3 (crop).
VIDEO OUT SEL VBS / HD Y VBS Selects the output from the VIDEO
OUT connector.
VBS: Output a composite signal.
HD Y: Output an HD Y signal.
i.LINK MODE AV/C / FAM AV/C – Selects the function of the i.LINK
connector.
LIVE&PLAY ON / OFF OFF 07 See “Viewing Camera Video during
Playback (Live & Play Function)”
on page 75.
OPERATION menu
No. Page Item Settings Default USER
menu
page
Description File
