Page 37

H H H C C

D D D G G

1 1 1 5 5

0 0 1 0 5

REF. PART NUMBER DESCRIPTION 2 5 0 0 0

1

353536-000

BH.NEEDLE POSITION CAM FOLLOWER LEVER LINK (RIGHT)

-

X

X

X

X

2

141913-451

BH.ND.POS.CAM FOLLOWER LEVER LINK (LEFT & RIGHT) SCREW

-

X

X

X

X

3

408030-000

BH.& FEED REGULATOR MECHANISM MTG.PLATE STUD RET.RING

-

X

X

X

X

4

445808-000

BH.& FEED REG.MECH.MTG.PLATE STUD SPRING WASHER

-

X

X

X

X

5

179949-000

BUTTONHOLER & FEED REG.MECH.MTG.PLATE STUD SPRING

-

X

X

X

X

6

445486-000

BH.BIGHT CONTROL CAM FOL.LEVER LINK (RIGHT) RET.RING

-

X

X

X

X

7

356230-000

BUTTONHOLER & FEED REGULATOR MECH.MTG.PLATE STUD

-

X

X

X

X

8

357012-938

BUTTONHOLER & FEED REGULATOR CAM COMPLETE

-

-

-

X

-

8

357010-947

BUTTONHOLER & FEED REGULATOR CAM COMPLETE

-

-

-

-

X

8

357012-937

BUTTONHOLER & FEED REGULATOR CAM COMPLETE

-

X

-

-

-

8

357010-945

BUTTONHOLER & FEED REGULATOR CAM COMPLETE

-

-

X

-

-

9

357013-458

BUTTONHOLER & FEED REGULATOR CAM ASSEMBLY

-

-

-

-

-

9

356959921

BUTTONHOLER & FEED REGULATOR CAM ASSEMBLY

-

-

-

-

-

9 357011-470 BUTTONHOLER & FEED REGULATOR CAM ASSEMBLY - - - - -

10

353304-000

FEED REGULATOR CONTROL ARM ASSEMBLY

-

X

X

X

X

11

141913-451

BUT. BIGHT CONT. CAM FOL. LEVER LINK(LEFT & RIGHT)SCREW

-

X

X

X

X

12

356748-000

BH.BIGHT CONTROL CAM FOLLOWER LEVER LINK (RIGHT)

-

X

X

X

X

13

356653481

FEED REGULATOR POSITIONING PIN KNOB

-

-

-

X

X

13

356653-480

FEED REGULATOR POSITIONING PIN KNOB

-

X

X

X

X

14

113513-451

BUTTONHOLER & FEED REGULATOR MECH.MTG.PLATE SCREW

-

X

X

X

X

15

445486-000

BH.RIGHT CONTROL CAM FOL.LEVER LINK (RIGHT) RET.RING

-

X

X

X

X

16

53640-819

BUTTONHOLER & FEED REG.MECH.MTG.PLATE SCREW NUT

-

X

X

X

X

17

353215-000

BUTTONHOLER NEEDLE POS.CAM FOLLOWER LEVER RET.RING

-

X

X

X

X

18

353495-000

BUTTONHOLER & FEED REG.CONTROL DIAL PAWL SPRING

-

X

X

X

X

19

353319-000

CAM CONTROL FEED ENG.CAM FOLLOWER & LEVER BUSHING

-

X

X

X

X

20

353321-000

CAM CONTROL FEED ENGAGING CAM FOLLOWER LEVER

-

X

X

X

X

21

353495-000

CAM CONTROL FEED ENG.CAM FOLLOWER & LEVER SPRING

-

X

X

X

X

22

353320-000

CAM CONTROL FEED ENGAGING CAM FOLLOWER

-

X

X

X

X

23

445539-000

CAM CONTROL FEED ENG.CAM FOLLOWER & LEVER WASHER

-

X

X

X

X

24

113372-451

CAM CONTROL FD.ENG.CAM FOLLOWER & LEVER MTG.SCREW

-

X

X

X

X

25

618638-005

FEED REGULATOR POSITIONING PIN CARRIER INSERT NUT

-

X

X

X

X

26

356650-000

FEED REGULATOR POSITIONING PIN

-

X

X

X

X

27

44892-000

FEED REGULATOR POSITIONING PIN FRICTION SPRING

-

X

X

X

X

28

357094-000

FEED REGULATOR POSITIONING PIN CARRIER

-

X

X

X

X

29

113455-001

FEED REGULATOR CONTROL ARM SCREW

-

X

X

X

X

30

356830-001

FEED REGULATOR POSITIONING PIN WASHER

-

X

X

X

X

BUTTONHOLER & FEED REGULATOR CAM
