164 SANRAD V-Switch User Manual
Removing all Volumes in a Hierarchy
If you are working in
a V-Switch cluster,
the volume must be
removed on both V-
Switches.
You can remove a volume and all of its component volumes in a volume
hierarchy. The volume must be at the top of the hierarchy. The volume
cannot be exposed; the volume LUN must be inactivated. Simple
volumes will convert back to subdisks.
volume remove -all
You need to define one parameter to remove all volumes within a volume
hierarchy:
SWITCH PARAMETER DEFINITION STATUS EXAMPLE
-all
ALL ALL VOLUMES IN
HIERARCHY
MANDATORY
No parameter
required
-vol
VOLUME ALIAS ALIAS OF TOP-
LEVEL VOLUME TO
REMOVE
MANDATORY
Stripe1
Example:
The top-level volume Stripe 1 is removed along with its component
volumes, Simple 2, 4, 8 & 10.
volume remove -all –vol Stripe1
