User Parameters
133
7
-
--
-
List of all relevant user parameters
Many bit settings have no effect and are not listed. (Never change these). The set-
tings made at the factory are underlined.
* : Default Settings
SW Digits & Definition Settings
00 0, 1, 2 and 3 Do not change these set-
tings
4, 5: Default resolution when you send a mes-
sage
RESOLUTION
HALFTONE
Bit: 4, 5
Standard*: 0, 0
Detail: 1, 0
Fine: 0, 1
Halftone: 1, 1
6: Default setting for transmission
TRANSMISSION MODE
Memory*: 0
Immediate: 1
01 7: Clear modes after sending a fax.
RETURN TO HOME POSITION
Off: 0
On*: 1
02 0: Mark to be printed at the receiving side to
distinguish messages that are sent from you
machine when it is acting as a forwarding sta-
tion.
FORWARDING MARK
Off: 0
On*: 1
1: The center mark is not printed when the ma-
chine is used for making copies.
CENTER MARK
Off* : 0
On: 1
3: Printing the sender's TSI on a receiving mes-
sage
TSI PRINTING
Off* : 0
On: 1
