PK120 Specications
Optical Specication (Panel)
Manufacturer Texas Instruments
Type DLP® 0.2 nHD DMD
Size 0.22 inches (diagonal)
Display pixels 640 x 360
Projection
image size
10” ~ 60”
Throw ratio 2.2
Horizontal
scan rate
31.5 ~ 48.4 KHz
Vertical scan rate 50 / 60 Hz
Aspect ratio 4:3, 16:9, Auto
Parameters
Internal memory 2GB NAND Flash
External memory micro SD card (up to 32 GB)
Brightness
Bright mode: 12lm
STD mode: 8lm
Luminance
Uniformity (JBMA)
50% (Minimum)
60% (Typical)
Contrast Ratio 1200:1 (Typical)
Projection Offset 100%
I/O Connectors
Universal (24-pin) to VGA IN x 1
Composite Video / Audio (Φ 2.5mm) x 1
microSD card slot x 1
Audio output (Φ 3.5mm) x 1
Micro USB x 1 (for data transfer / charging)
Input Signal Specication
Analog RGB signal
(PC)
Analog RGB 0.7 +/- 0.1 •
Vp-p, 75 ohm
Separate TTL, H, V Sync•
Video signal
NTSC / PAL Compsite video 1.0
+/- 0.1 Vp-p, 75 ohm
Audio signal
(Share with A/V input jack)
300mVrms, 22K ohm
AV-IN
Audio input: 0 ~ 1 Vrms
Video input: 0.5 ~ 1.8 Vp-p
Output Signal Specication
Micro USB X 1
(Device/Battery charge)
Host support < 150mA 5V
Audio out 3.5Ψmm jack
Speaker Built-in stereo speaker 0.5W x 2
Video Compatibility
NTSC NTSC M/J 3.58MHz, 4.43MHz
PAL PAL B/D/G/HI/M/N, 4.43MHz
SDTV 480i, 576i
RGB 480i / 480P, 576i / 576P
Computer Compatibility
VESA standards, PC & Macintosh compatible
Physical Specications
Weight 145g (with battery)
Dimensions
(L x W x H)
117 x 60 x 21 mm
Charging time 2.5 hours
Operating time
Video: 80 min (high brightness)
Music: 4.5 hours
Operating
temperature
0° ~ 30°C (32°F ~ 86°F)
Storage
temperature
-20° ~ 60°C
Humidity
10 ~ 40% RH
(without condensation)
0 ~ 1829 m (0 ~ 6000 feet)
above sea level
Power Specications
Battery 3.7V, 1800mAh
Power supply 5V, 2A, 110 ~ 240V
Charging time 2.5 hours
Battery operating
temperature
Charge: 0° ~ 45°C
Discharge: -20° ~ 60°C
Specications are subject to change without prior
notice.
te c h n I c a l Spe cIf IcatIon
HDPY2001010
P/N 36.00040G011- B
