Specifications
n Performance
Signal format : NTSC, PAL
Applicable discs /memory device : (1) BD-Video disc :
12 cm, 1 side, 1 layer; 12 cm, 1 side, 2 layers
(2) DVD-Video / DVD-Audio disc :
12 cm, 1 side, 1 layer; 12 cm, 1 side, 2 layers /
12 cm, 2 sides, 2 layers (1 side, 1 layer)
8 cm, 1 side, 1 layer; 8 cm, 1 side, 2 layers /
8 cm, 2 sides, 2 layers (1 side, 1 layer)
(3) Super Audio CD :
12 cm, 1 layer / 12 cm, 2 layer / 12 cm, Hybrid
(4) Compact Disc (CD-DA) :
12 cm / 8 cm disc
(5) Memory device :
USB memory device (USB 2.0)
HDMI output : Output terminal : 19-pin HDMI terminals, 1 set
(Deep Colour, Dolby Digital Plus, Dolby TrueHD, DTS-HD, 3D)
Analog audio output : Output level : 2 Vrms (10 kΩ)
2 channels output terminal : Pin-jack, 1 set
Audio output characteristics : (1) Frequency response
q BD (Linear PCM)
w DVD (Linear PCM)
e Super Audio CD
r CD
: 2 Hz - 22 kHz (48 kHz sampling)
: 2 Hz - 44 kHz (96 kHz sampling)
: 2 Hz - 88 kHz (192 kHz sampling)
: 2 Hz - 22 kHz (48 kHz sampling)
: 2 Hz - 44 kHz (96 kHz sampling)
: 2 Hz - 88 kHz (192 kHz sampling)
: 2 Hz - 40 kHz
: 2 Hz - 20 kHz
(2) S/N ratio : 115 dB (BD)
(3) Total harmonic distortion : 1 kHz, 0.0025 % (BD)
(4) Dynamic range : 100 dB (BD)
n General
Power supply : AC 120 V, 60 Hz
Power consumption :
(vpage37 “Energy Saving Mode”)
20 W
0.3 W (Energy Saving Standby)
0.5 W (Normal Standby)
12 W (Quick Start)
z For purposes of improvement, specifications and design are subject to change without notice.
GRemote control unitH
Symptom Cause/Solution Page
The set cannot be
operated with the
remote control.
•Aim the remote control directly at the infrared sensor window on
the front of the unit.
•Operate within a distance of 23 ft / 7 m from the remote control
sensor.
•Remove any obstacles.
•Replace the batteries with new ones.
•Insert the batteries in the proper direction, checking the q and
w marks.
•Match the signal code of the remote control to the signal code of
the unit.
•Check whether the remote sensor of the unit is exposed to direct
sunlight or strong light of a fluorescent lamp, 3D synchro signal of
TV. Be sure to avoid exposing the remote sensor to strong light.
•The switch on the back of the
REMOTE CONTROL is on “EXT.
(EXTERNAL)”. When using this unit independently, set the switch
to “INT. (INTERNAL)”.
48
48
48
48
48
40,49
48
10
•Some functions may not be used under certain operating conditions, but this is not failure of the unit.
Read the description in this Owner’s Manual for details on correct operations.
•The volume may differ from disc to disc. This is due to the differences in how the signals are recorded
on the disc and is not a malfunction.
•During programmed playback, it is not possible to perform random playback or to start playback from a
desired track or file.
•Some functions are prohibited on some discs.
