REPLACEMENT PARTS
No. DESCRIPTION Part No. Qty. Part No. Qty.
Fireplace Assembly – – – –
1. Firescreen 19M28 2 30M31 2
2. Rod, Screen 19M29 2 19M29 2
3. Refractory, Side, Right (Traditional) 19M25 1 – 1
Refractory, Side, Right (Herringbone) – 1 20M33 1
4. Refractory, Side, Left (Traditional) 19M24 1 – 1
Refractory, Side, Left (Herringbone) – 1 20M32 1
5. Refractory, Rear (Traditional) 19M26 1 – 1
Refractory, Rear (Herringbone) – 1 20M34 1
6. Refractory Base 19M23 1 19M23 1
7. Grate 19M27 1 19M27 1
COL-3629 COL-3629H
