CHIMNEY - PARTS AND COMPONENTS LISTS
Secure Temp ASHT+ 1” High Temp. Insulated Stainless Steel Chimney
10” I.D., Double-Wall Stainless Steel, Listed to CAN/UCL-S604 & UL-103HT
Description Part/Cat. No.
Lengths and Misc. Chimney Components
8” length, 10” Dia., 10L8-N 10L8-N
12” length, 10” Dia., 10L12-N 10L12-N
18” length, 10” Dia., 10L18-N 10L18-N
24” length, 10” Dia., 10L24-N 10L24-N
36” length, 10” Dia., 10L36-N 10L36-N
48” length, 10” Dia., 10L48-N 10L48-N
Adjustable Length 12”, 10” Dia., 10LA 10LA
15º elbow, 10” Dia., 10E15 10E15
30º elbow, 10” Dia., 10E30 10E30
Rain Termination Cap, 10” Dia., 10CC 10CC
Spark Arrester Screen (universal spark arrester band), PE PE
Wall Band, XBM XBM
Supports
Offset Support, XSO XSO
Roof Support, XST XST
Roof Brace, BS2 BS2
Firestops
Firestop, 10BF 10BF
Radiation Shield, 10RS 10RS
Insulated Attic Radiation Shield, 10RSA2 10RSA2
Insulated Wall Radiation Shield, 10RSM 10RSM
Insulated Wall Radiation Shield, 30º, 10RSMI30 10RSMI30
Uninsulated Wall Radiation Shield, 30º, 10RSM30 10RSM30
Roof Flashings
Flat Roof Flashing, 10FR 10FR
1/12 - 7/12 (5º - 30º), 10FAR 10FAR
8/12 - 12/12 (30º - 45º), 10FBR 10FBR
Storm Collar, 10FC 10FC
Anchor Plate, 10SP 10SP
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
