36
You can use the supplied remote control to operate not only
this receiver but also other JVC products.
• Refer also to the manuals supplied with the other products.
– Some JVC VCRs can accept two types of the control
signals—remote codes “A” and “B.” This remote control can
operate a VCR whose remote control code is set to “A.”
• To operate other products, aim the remote control directly at the
remote sensor on the target product.
7 TV
Operating other
JVC products
Operating other JVC products
You can always perform the following operations:
TV : Turn on or off the TV.
TV VOL +/–: Adjust the volume on the TV.
TV/VIDEO: Change the input mode (either video input
or TV tuner) on the TV.
After pressing TV, you can perform the following operations on the
TV.
CHANNEL +/–: Change the channel numbers.
1 – 9, 0, 100+: Select the channel numbers.
TV RETURN (10): Function as the TV RETURN button.
Set the mode selector to
“AUDIO/TV/VCR/STB.”
7 VCR
You can always perform the following operation:
VCR : Turn on or off the VCR.
After pressing VCR, you can perform the following operations on
the VCR.
CHANNEL +/–: Change the channel numbers on the VCR.
1 – 9, 0: Select the channel numbers on the VCR.
3: Start playback.
7: Stop playback.
8: Pause playback. To release it, press 3.
¡: Fast-wind a tape.
1: Rewind a tape.
REC PAUSE: Enter recording pause. To start recording,
press this button then 3.
Set the mode selector to
“AUDIO/TV/VCR/STB.”
